NI GPIB-140A總線擴展器 GPIB總線擴展器 - GPIB-140A可將GPIB系統的線纜延長一千米，而不會影響GPIB的完整性，也無需修改軟件。該配件使用緩沖傳輸技術，數據傳輸速率高達1.1 Mb/s (IEEE 488.1)或2.8 Mb/s (HS488)。GPIB-140A還可以將GPIB系統中GPIB設備的最大數量從15個增加到26個。
