BENTLY 3500/44M 176449-03 振動監視器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Bently 3500/44M 176449-03 是一款用于工業設備振動監測的高性能振動監視器，專為監測旋轉機械（如泵、風機、壓縮機等）中的振動信號而設計。該產品是 Bently Nevada（貝爾特·內華達）公司生產的 3500 系列監測系統 的一部分，用于提供實時振動數據和報警，幫助監控設備健康，預防設備故障，確保設備的長期穩定運行。
主要特點與功能：
監測功能：
- 多通道輸入： 3500/44M 振動監視器可以監測多通道信號，通?？梢酝瑫r(shí)接收多個振動傳感器的輸入，用于綜合分析設備的運行狀態。
- 寬頻率響應： 支持廣泛的頻率范圍，適應不同機械設備的工作條件。通常，它可以捕捉到從低頻到高頻的振動信號，覆蓋從轉速相關的低頻到機械故障相關的高頻。
- 實時振動分析： 通過處理信號，提供實時振動數據，有助于在振動異常時及時發出報警。
高級報警功能：
- 報警設置： 支持設置不同的報警閾值，當設備的振動超出預設范圍時，設備會觸發報警信號，提醒操作人員進行維護。
- 報警優先級： 根據振動幅度、頻率等參數，可設置多種不同優先級的報警，以便在發生故障時快速識別問題嚴重性。
數據記錄與分析：
- 數據存儲： 可以存儲歷史數據，幫助分析設備的振動趨勢，進行故障診斷和預測維護。
- 趨勢分析： 支持?jǐn)?shù)據分析和趨勢記錄，幫助識別設備的潛在故障點，提前采取措施，避免意外停機。
傳感器兼容性：
- 支持多種類型的振動傳感器： 包括加速度計、速度傳感器和位移傳感器等，可以根據需要選擇合適的傳感器與 3500/44M 配合使用。
- 自動識別傳感器： 3500 系列系統能夠自動識別所連接的傳感器類型和輸入信號。
英文資料：
Bently 3500/44M 176449-03 is a high-performance vibration monitor designed for industrial equipment vibration monitoring, specifically for monitoring vibration signals in rotating machinery such as pumps, fans, compressors, etc. This product is part of the 3500 series monitoring system produced by Bently Nevada, used to provide real-time vibration data and alarms, help monitor equipment health, prevent equipment failures, and ensure long-term stable operation of equipment.
Main features and functions:
Monitoring function:
Multi channel input: The 3500/44M vibration monitor can monitor multi-channel signals and typically receive inputs from multiple vibration sensors simultaneously, used for comprehensive analysis of equipment operation status.
Broadband response: Supports a wide frequency range and adapts to the working conditions of different mechanical equipment. Usually, it can capture vibration signals from low frequency to high frequency, covering from low frequency related to speed to high frequency related to mechanical faults.
Real time vibration analysis: By processing signals and providing real-time vibration data, it helps to issue alarms in a timely manner when there are abnormal vibrations.
Advanced alarm function:
Alarm settings: Support setting different alarm thresholds. When the vibration of the device exceeds the preset range, the device will trigger an alarm signal to remind the operator to perform maintenance.
Alarm priority: Based on parameters such as vibration amplitude and frequency, multiple alarms with different priorities can be set to quickly identify the severity of the problem in the event of a malfunction.
Data recording and analysis:
Data storage: It can store historical data to help analyze equipment vibration trends, diagnose faults, and predict maintenance.
Trend analysis: supports data analysis and trend recording to help identify potential failure points of equipment, take measures in advance, and avoid unexpected downtime.
Sensor compatibility:
Supports multiple types of vibration sensors, including accelerometers, velocity sensors, and displacement sensors. Suitable sensors can be selected according to needs to be used in conjunction with the 3500/44M.
Automatic recognition sensor: The 3500 series system can automatically recognize the type of sensor and input signal connected.
2.產 品 展 示
