ABB PPD117A3011 3BHE030410R3011激勵控制器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
PPD117A3011（產品代碼：3BHE030410R3011）是ABB公司生產的勵磁控制器模塊，廣泛應用于電力系統、發電機組和工業過程控制等領域。該模塊通過調節勵磁電流，控制發電機的輸出電壓，確保電力系統的穩定運行。
主要特點：
精確的電壓調節： 通過調節勵磁電流，控制發電機的輸出電壓，確保電力系統的穩定運行。
實時反饋控制： 實時監測發電機的運行狀態，并根據反饋信號自動調節勵磁電流，以保證電壓在設定范圍內。
高可靠性： 設計用于高可靠性要求的工業環境，能夠適應極端操作條件，如溫度變化、電流波動等。
多種保護功能： 內置過電壓、過電流、欠電壓等保護功能，提高設備的安全性，防止故障發生。
靈活配置： 支持多種通訊協議和接口，可以方便地與其他自動化設備或控制系統集成，適應不同的控制需求。
現代化控制技術： 結合數字化控制技術，提供更高的精度和更快的響應速度。
應用領域：
電力發電： 在電力發電廠中，用于控制發電機的勵磁系統，保持發電機的穩定運行。
工業應用： 用于各種工業發電機組或電動機的勵磁控制，確保電力供應的穩定性和高效性。
電網系統： 幫助調節電網電壓，確保電力系統的穩定和高效運行，避免因電壓波動導致的設備損壞。
自動化控制： 與其他控制系統集成，提供精確的電壓控制和電力調度。
優勢：
高穩定性和可靠性： 確保長期穩定運行，即使在惡劣環境下也能保持優異的控制效果。
精確的電壓調節： 有助于減少電力系統的波動，保護設備免受電壓波動損害。
多重保護功能： 確保設備在各種故障情況下的安全性。
適應性強： 能夠與不同類型的發電機組、電動機和控制系統無縫集成，提供靈活的控制解決方案。
英文資料：
PPD117A3011 (product code: 3BHE030410R3011) is an excitation controller module produced by ABB, widely used in fields such as power systems, generator sets, and industrial process control. This module controls the output voltage of the generator by adjusting the excitation current, ensuring the stable operation of the power system.
Main features:
Accurate voltage regulation: By adjusting the excitation current, the output voltage of the generator is controlled to ensure the stable operation of the power system.
Real time feedback control: Real time monitoring of the operating status of the generator and automatic adjustment of the excitation current based on feedback signals to ensure that the voltage is within the set range.
High reliability: designed for industrial environments with high reliability requirements, able to adapt to extreme operating conditions such as temperature changes, current fluctuations, etc.
Multiple protection functions: Built in overvoltage, overcurrent, undervoltage and other protection functions to improve equipment safety and prevent faults from occurring.
Flexible configuration: Supports multiple communication protocols and interfaces, making it easy to integrate with other automation devices or control systems to meet different control requirements.
Modern control technology: Combining digital control technology to provide higher accuracy and faster response speed.
Application areas:
Electric power generation: In a power plant, it is used to control the excitation system of the generator and maintain its stable operation.
Industrial application: Used for excitation control of various industrial generator sets or motors, ensuring the stability and efficiency of power supply.
Power grid system: helps regulate the voltage of the power grid, ensuring the stable and efficient operation of the power system, and avoiding equipment damage caused by voltage fluctuations.
Automated control: Integrated with other control systems to provide precise voltage control and power dispatch.
Advantages:
High stability and reliability: Ensure long-term stable operation and maintain excellent control performance even in harsh environments.
Accurate voltage regulation: helps reduce fluctuations in the power system and protect equipment from voltage fluctuations.
Multiple protection functions: Ensure the safety of the device in various fault situations.
Strong adaptability: able to seamlessly integrate with different types of generator sets, motors, and control systems, providing flexible control solutions.
2.產 品 展 示
