GE IS220YAICS1A 分析模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
IS220YAICS1A 是 GE（通用電氣）Mark VIe 控制系統中的I/O 分析模塊，專為燃氣輪機、蒸汽輪機及其他工業過程控制應用而設計。它主要用于信號采集、處理和數據分析，并能夠與Mark VIe 控制器（如 IS420UCSCH1A） 無縫集成。
1. 主要特點
? 先進的信號分析功能
具備高速數據采集和信號處理能力，用于狀態監測、振動分析、溫度監測等應用。
適用于燃氣輪機、蒸汽輪機、壓縮機等旋轉設備的狀態監測和保護。
? 兼容 GE Mark VIe & Mark VIeS 控制系統
作為 GE Mark VIe 控制架構的一部分，與其他 I/O 模塊、控制器和 HMI 無縫集成。
通過Ethernet 連接到 Mark VIe 控制器，實現遠程數據傳輸和實時監測。
? 多種工業通信協議支持
支持 Modbus TCP/IP、Profinet、Ethernet/IP 等主流工業協議，可用于多系統互聯。
提供冗余通信，確保數據傳輸?shù)目煽啃院桶踩浴?/p>
? 高可靠性 & 冗余設計
符合**SIL3（安全完整性等級3）**標準，適用于關鍵過程安全應用。
雙冗余架構，可配合雙控制器運行，確保在故障時快速切換，減少停機時間。
? 工業級環境適應性
適用于高溫、高濕、高振動等嚴苛工業環境。
低功耗設計，支持長期穩定運行。
2. 技術規格
| 參數 | 詳細信息 |
|---|---|
| 模塊類型 | 分析 I/O 模塊 |
| 輸入類型 | 多通道模擬/數字輸入 |
| 通信接口 | 以太網（冗余支持）、Modbus TCP/IP、Profinet |
| 兼容性 | GE Mark VIe & Mark VIeS 控制系統 |
| 安全認證 | SIL3 認證 |
| 工作環境 | 適用于高溫、高濕、振動等工業環境 |
| 數據處理能力 | 實時信號采集、分析和處理 |
英文資料：
IS220YAICS1A is an I/O analysis module in the GE Mark VIe control system, designed specifically for gas turbines, steam turbines, and other industrial process control applications. It is mainly used for signal acquisition, processing, and data analysis, and can be seamlessly integrated with Mark VIe controllers (such as IS420UCSCH1A).
1. Main features
? Advanced signal analysis capabilities
Capable of high-speed data acquisition and signal processing, used for applications such as condition monitoring, vibration analysis, temperature monitoring, etc.
Suitable for status monitoring and protection of rotating equipment such as gas turbines, steam turbines, compressors, etc.
? Compatible with GE Mark VIe&Mark VIeS control systems
As part of the GE Mark VIe control architecture, it seamlessly integrates with other I/O modules, controllers, and HMIs.
Connect to the Mark VIe controller via Ethernet for remote data transmission and real-time monitoring.
? Multiple industrial communication protocols supported
Supports mainstream industrial protocols such as Modbus TCP/IP, Profinet, Ethernet/IP, and can be used for multi system interconnection.
Provide redundant communication to ensure the reliability and security of data transmission.
? High reliability&redundancy design
Compliant with SIL3 (Safety Integrity Level 3) standards and suitable for critical process safety applications.
The dual redundant architecture can operate in conjunction with dual controllers, ensuring quick switching in case of failure and reducing downtime.
? Industrial grade environmental adaptability
Suitable for harsh industrial environments such as high temperature, high humidity, and high vibration.
Low power design, supporting long-term stable operation.
2. Technical specifications
Detailed parameter information
Module Type Analysis I/O Module
Input type: multi-channel analog/digital input
Communication interface Ethernet (redundant support) Modbus TCP/IP、Profinet
Compatibility with GE Mark VIe&Mark VIeS control system
Safety certification SIL3 certification
The working environment is suitable for industrial environments such as high temperature, high humidity, and vibration
Real time signal acquisition, analysis, and processing capabilities for data processing
2.產 品 展 示
