GE 193X256ABG02放大器板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X256ABG02 放大器板 是 GE（General Electric）193X 系列控制系統中的一款模擬信號放大模塊，廣泛應用于 GE 工業驅動控制系統中，特別是在直流調速驅動器和大型電機控制裝置中。它是 193X256ABG01 的升級或變種型號，主要用于增強和調理輸入信號，以供系統做進一步的控制處理。
產品概述：
型號：193X256ABG02
品類：模擬信號放大電路板
系列：GE 193X 系列控制模塊
用途：信號放大、隔離與調理，適用于閉環控制系統
核心功能：
信號放大
將外部反饋信號（如速度、電壓、電流）放大到合適的控制電平，供后續控制邏輯模塊處理。噪聲濾除與信號調理
提供電氣隔離與濾波功能，提高系統抗干擾能力，確保信號純凈性和控制精度。模擬信號接口轉換
可將低電平模擬信號轉換成高電平控制信號，或與數字/模擬轉換器（ADC/DAC）配合使用。
應用領域：
工業電機調速系統（特別是 DC 驅動器）
GE Mark 系列控制系統（如 Mark II, Mark IV 等）
發電廠勵磁控制系統
能源、冶金、造紙等重工業自動化控制設備
鐵路牽引與電力驅動裝置
英文資料：
The GE 193X256ABG02 amplifier board is an analog signal amplification module in the GE (General Electric) 193X series control system, widely used in GE industrial drive control systems, especially in DC speed control drives and large motor control devices. It is an upgraded or variant model of 193X256ABG01, mainly used to enhance and condition input signals for further control processing by the system.
Product Overview:
Model: 193X256ABG02
Category: Analog Signal Amplification Circuit Board
Series: GE 193X series control module
Purpose: Signal amplification, isolation, and conditioning, suitable for closed-loop control systems
Core functions:
signal amplification
Amplify external feedback signals (such as speed, voltage, current) to appropriate control levels for subsequent control logic module processing.
Noise filtering and signal conditioning
Provide electrical isolation and filtering functions to improve the system's anti-interference ability, ensure signal purity and control accuracy.
Analog signal interface conversion
Low level analog signals can be converted into high-level control signals, or used in conjunction with digital/analog converters (ADC/DAC).
Application areas:
Industrial motor speed control system (especially DC drive)
GE Mark series control systems (such as Mark II, Mark IV, etc.)
Excitation control system for power plants
Automation control equipment for heavy industries such as energy, metallurgy, and papermaking
Railway traction and electric drive devices
2.產 品 展 示
