GE 193X532ADG01現場控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X532ADG01 是 General Electric（通用電氣）公司 193X 系列中的一款現場控制板，廣泛應用于早期 GE 工業驅動系統中，尤其是在直流和交流驅動裝置、過程控制系統中，起到核心的現場信號處理和控制指令執行作用。該板卡通常安裝于控制機架或控制柜中，與系統內其他功能模塊協同運行。
技術規格與功能特點
控制類型：模擬信號控制為主，輔以部分?jǐn)?shù)字邏輯功能
輸入信號：標準工業模擬信號（如 0–10V、4–20mA）、數字觸點
輸出信號：控制電壓/電流、開關信號、邏輯控制信號
工作電壓：一般為 ±15V DC（系統供電）
調節功能：板載多圈電位器，用于調節增益、零點、響應等參數
電路組成：采用分立電子元器件（運放、晶體管、電容電阻等）構建穩定控制邏輯
接口形式：插卡式金手指設計，連接到 GE 控制機箱背板
狀態指示：部分版本帶有狀態 LED 燈，用于調試與運行指示
應用范圍
GE 早期 Mark 系列驅動控制系統
直流/交流電機調速系統
冶金行業電機控制
電廠勵磁控制系統
化工、造紙、能源等連續控制流程中的執行機構控制
安裝與使用注意事項
安裝前確保系統完全斷電，插拔過程避免觸電或損傷接口。
使用時注意防靜電處理，防止靜電放電損傷電路元件。
使用前應仔細核對板卡的接線定義、輸入輸出信號類型與系統要求是否一致。
建議定期（每 6–12 個月）對控制板進行檢查，包括電容老化、焊點虛焊、接觸不良等問題。
調試過程中可使用示波器、萬用表測量關鍵點信號波形或電壓值，判斷電路是否正常。
英文資料：
GE 193X532ADG01 is a field control board in General Electric's 193X series, widely used in early GE industrial drive systems, especially in DC and AC drive devices and process control systems, playing a core role in field signal processing and control instruction execution. This board is usually installed in the control rack or control cabinet and operates in conjunction with other functional modules within the system.
Technical specifications and functional features
Control type: mainly analog signal control, supplemented by some digital logic functions
Input signals: standard industrial analog signals (such as 0-10V, 4-20mA), digital contacts
Output signals: control voltage/current, switch signal, logic control signal
Working voltage: generally ± 15V DC (system power supply)
Adjustment function: onboard multi turn potentiometer, used to adjust parameters such as gain, zero point, response, etc
Circuit composition: Using discrete electronic components (operational amplifiers, transistors, capacitors, resistors, etc.) to construct stable control logic
Interface form: Card type gold finger design, connected to the back panel of GE control chassis
Status indicator: Some versions come with status LED lights for debugging and running instructions
Application scope
GE Early Mark Series Drive Control System
DC/AC motor speed control system
Motor control in metallurgical industry
Power plant excitation control system
Control of actuators in continuous control processes such as chemical, papermaking, and energy industries
Installation and usage precautions
Ensure that the system is completely powered off before installation, and avoid electric shock or damage to the interface during the plugging and unplugging process.
Pay attention to anti-static treatment during use to prevent static discharge from damaging circuit components.
Before use, carefully check whether the wiring definition, input and output signal types of the board are consistent with the system requirements.
It is recommended to regularly (every 6-12 months) inspect the control board, including issues such as capacitor aging, solder joint virtual soldering, and poor contact.
During the debugging process, oscilloscopes and multimeters can be used to measure the waveform or voltage values of key point signals to determine if the circuit is functioning properly.
2.產 品 展 示
