GE 193X536AAG01過度板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X536AAG01 是美國通用電氣（General Electric）公司生產的 193X 系列自動化控制系統中的專用過渡板（Transition Board）。該模塊通常作為主控制板與信號執行單元之間的中介接口板，用于完成信號的引出、轉接、隔離、緩沖或物理位置過渡等功能，是整個工業驅動控制系統中不可或缺的連接部件。
技術參數與結構特點
產品類型：過渡板 / 接口轉換板（Transition Board）
適配系統：GE 193X 系列自動化控制系統
結構形式：插卡式 PCB 模塊，帶有多路金手指端口與外接引腳接口
功能定位：
信號從控制板到外設的過渡與引出
執行模塊信號匯總并反饋至主控模塊
電氣信號緩沖或光隔離
接口類型：一側為標準金手指插槽接口，另一側為螺絲端子或多芯插件連接
適用信號類型：模擬量信號、數字控制信號、電源傳輸線纜等
工作電壓范圍：根據系統供電等級（典型為 ±15V DC 或 24V 控制電源）
耐溫范圍：工業級，典型為 -20°C ~ +70°C
應用場合
GE DC/AC 電機驅動控制系統
大型自動化設備的信號轉接與引線管理
工業現場環境中主控制板與遠程 I/O 之間的連接
工控系統改造中舊款控制板的接口過渡應用
具備空間限制或多種信號線纜集成需求的設備
英文資料：
GE 193X536AAG01 is a specialized transition board in the 193X series automation control system produced by General Electric in the United States. This module usually serves as an intermediate interface board between the main control board and the signal execution unit, used to complete functions such as signal output, conversion, isolation, buffering, or physical position transition. It is an indispensable connecting component in the entire industrial drive control system.
Technical parameters and structural characteristics
Product type: Transition Board/Interface Conversion Board
Adaptation System: GE 193X Series Automation Control System
Structural form: Plug in PCB module with multiple gold finger ports and external pin interfaces
Functional positioning:
Transition and extraction of signals from control board to peripherals
Summarize module signals and provide feedback to the main control module
Electrical signal buffering or optical isolation
Interface type: One side is a standard gold finger slot interface, and the other side is a screw terminal or multi-core plug-in connection
Applicable signal types: analog signal, digital control signal, power transmission cable, etc
Working voltage range: Depending on the system power supply level (typically ± 15V DC or 24V control power supply)
Temperature resistance range: industrial grade, typically -20 ° C~+70 ° C
Application scenarios
GE DC/AC motor drive control system
Signal transfer and lead management of large-scale automation equipment
The connection between the main control board and remote I/O in industrial field environment
Interface Transition Application of Old Control Boards in Industrial Control System Renovation
Equipment with space limitations or multiple signal cable integration requirements
