GE 193X537ADG01直流驅動主控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X537ADG01 是通用電氣公司（General Electric）在其 193X 系列直流驅動控制系統中推出的主控制板（Main Control Board）。該板卡在 GE 直流驅動系統中扮演著核心角色，負責整個驅動系統的主控制邏輯，包括電機的速度控制、勵磁調節、保護機制等功能。
技術規格與功能特點
產品類型：直流驅動主控制板
控制方式：模擬信號調節與數字控制邏輯相結合
輸入信號：包括電壓、電流、速度反饋、編碼器信號等
輸出信號：控制功率模塊的驅動信號、反饋信號、報警信號等
電源要求：典型工作電壓為 ±15V DC（通過系統電源提供）
信號輸入與輸出：支持模擬量輸入（如速度、電流反饋）、數字信號輸入（如開關觸點、啟動命令）
狀態顯示：板上可能包含 LED 狀態指示燈，用于顯示系統運行狀態或故障診斷
調節功能：具有增益調節、偏移調節、響應時間調節等板載功能，用于調整控制精度和性能
元件配置：包含高精度電阻、電位器、晶體管、運算放大器等用于實現精確控制的核心元件
工作溫度：典型工作溫度范圍為 -20°C 至 +70°C
應用領域
GE 直流驅動系統：如 GE Mark I、II、IV 等系列電機控制系統
電機控制與調速系統：主要用于直流電機的速度調節和勵磁控制
工業自動化：在冶金、電力、石油化工、造紙等行業中廣泛應用
替換與升級：用于老舊控制系統的維護和升級，替換舊款控制板以提高系統可靠性
動力驅動系統：適用于大型機械設備，如風機、水泵、傳送帶等自動化驅動控制
英文資料：
GE 193X537ADG01 is the Main Control Board introduced by General Electric in its 193X series DC drive control system. This board plays a core role in the GE DC drive system, responsible for the main control logic of the entire drive system, including motor speed control, excitation regulation, protection mechanism, and other functions.
Technical specifications and functional features
Product type: DC drive main control board
Control method: Combining analog signal regulation with digital control logic
Input signals: including voltage, current, speed feedback, encoder signals, etc
Output signals: control the driving signal, feedback signal, alarm signal, etc. of the power module
Power requirement: The typical operating voltage is ± 15V DC (provided by the system power supply)
Signal input and output: Supports analog input (such as speed and current feedback) and digital signal input (such as switch contacts and start commands)
Status display: The board may include LED status indicators to display the system's operating status or fault diagnosis
Adjustment function: It has onboard functions such as gain adjustment, offset adjustment, and response time adjustment, used to adjust control accuracy and performance
Component configuration: including high-precision resistors, potentiometers, transistors, operational amplifiers, and other core components used to achieve precise control
Working temperature: The typical working temperature range is -20 ° C to+70 ° C
application area
GE DC drive system: such as GE Mark I, II, IV series motor control systems
Motor control and speed regulation system: mainly used for speed regulation and excitation control of DC motors
Industrial automation: widely used in industries such as metallurgy, power, petrochemicals, and papermaking
Replacement and Upgrade: Used for maintenance and upgrade of old control systems, replacing old control boards to improve system reliability
Power Drive System: Suitable for automated drive control of large mechanical equipment such as fans, water pumps, conveyors, etc
2.產 品 展 示
