GE 193X643ABG222控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X643ABG222 控制板技術說明
GE 193X643ABG222 是通用電氣（General Electric）193X 系列中的一款功能控制板，常用于 GE 的工業自動化系統和驅動控制系統中，執行關鍵的控制邏輯、信號處理與模塊協調功能。該板卡以高可靠性、模塊化設計著稱，是多種 GE 經典驅動系統的重要組成部分。
基本參數
型號：193X643ABG222
名稱：控制板（Control Board）
制造商：General Electric (GE)
系列：GE 193X 系列
類型：功能邏輯控制模塊
結構類型：插槽式 PCB 板卡，金手指接口
電源要求：+5V DC / ±15V DC（來自系統主電源或電源模塊如 193X643ABG110）
工作溫度范圍：-20°C ～ +70°C
外形規格：標準 193X 系列板卡尺寸
功能特點
系統邏輯控制核心：作為系統的主要控制邏輯模塊，協調執行各類控制命令。
信號處理與變換：接收來自傳感器、其他控制板的信號，并進行放大、濾波、處理等操作。
控制信號輸出：為執行單元（如繼電器、驅動模塊、電動機）輸出控制邏輯信號。
模塊化設計：方便維護、更換與系統擴展，適用于各種 GE 控制系統組合。
可靠性設計：采用工業級電子元件，抗干擾性能優異，適應高溫、高濕、高震環境。
狀態指示功能：部分版本帶有 LED 狀態指示，用于調試與運行狀態監控。
英文資料：
Technical Description of GE 193X643ABG222 Control Board
GE 193X643ABG222 is a functional control board in the General Electric 193X series, commonly used in GE's industrial automation and drive control systems to perform critical control logic, signal processing, and module coordination functions. This board is known for its high reliability and modular design, and is an important component of various GE classic drive systems.
Basic parameters
Model: 193X643ABG222
Name: Control Board
Manufacturer: General Electric (GE)
Series: GE 193X Series
Type: Functional Logic Control Module
Structure type: slot type PCB board, gold finger interface
Power requirement:+5V DC/± 15V DC (from the system main power supply or power module such as 193X643ABG110)
Working temperature range: -20 ° C to+70 ° C
Exterior specifications: Standard 193X series board size
Functional Features
System logic control core: As the main control logic module of the system, it coordinates the execution of various control commands.
Signal processing and transformation: Receive signals from sensors and other control boards, and perform operations such as amplification, filtering, and processing.
Control signal output: Output control logic signals for execution units (such as relays, drive modules, motors).
Modular design: convenient for maintenance, replacement, and system expansion, suitable for various combinations of GE control systems.
Reliability design: using industrial grade electronic components with excellent anti-interference performance, suitable for high temperature, high humidity, and high vibration environments.
Status indication function: Some versions come with LED status indication for debugging and running status monitoring.
