GE 193X643ADG114靜態控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X643ADG114 是通用電氣（General Electric）193X 系列中的一款高性能靜態控制器（Static Regulator / Static Controller），主要用于 GE 工業控制系統中，對電機或變頻驅動系統進行精確的電壓、電流調節與動態響應控制。該模塊通過靜態電子器件（如晶閘管、放大器等）實現高效、無機械磨損的穩態調節。
基本參數
產品型號：193X643ADG114
產品名稱：靜態控制器（Static Regulator / Static Controller）
所屬系列：GE 193X 控制板卡系列
制造商：General Electric (GE)
電源要求：+5V / ±15V DC（由系統電源模塊如193X643ABG供給）
安裝方式：插槽式安裝，背板連接
工作溫度范圍：-20°C 至 +70°C
外形規格：標準 PCB 板卡，帶金手指插頭
功能特點
靜態調節器核心功能：實現對系統中電壓、電流、頻率的靜態調節，替代傳統機械式調節元件；
響應快速：采用半導體放大和控制元件，實現毫秒級快速調節；
穩定性強：可長期連續工作于高頻切換控制系統中，具備電壓/電流閉環調節功能；
控制邏輯集成：內嵌關鍵邏輯、運算及比較電路，實現反饋控制閉環；
抗干擾設計：具備輸入信號濾波、過電壓保護、短路保護功能；
指示功能：配有狀態指示燈（LED），用于運行狀態和故障診斷（部分版本支持）。
應用場景
GE 發電廠自動控制系統（如汽輪發電機組）
大功率直流/交流電動機驅動系統控制
GE Mark II / Mark IV 驅動與勵磁系統
冶金、造紙、化工等連續生產線調速系統
高壓變頻器及逆變器中的穩壓控制模塊
英文資料：
GE 193X643ADG114 is a high-performance Static Regulator/Controller in the General Electric 193X series, mainly used in GE industrial control systems for precise voltage and current regulation and dynamic response control of motors or variable frequency drive systems. This module achieves efficient and mechanical wear free steady-state regulation through static electronic devices such as thyristors, amplifiers, etc.
Basic parameters
Product model: 193X643ADG114
Product Name: Static Regulator/Static Controller
Series: GE 193X Control Board Series
Manufacturer: General Electric (GE)
Power requirement:+5V/± 15V DC (supplied by the system power module such as 193X643ABG)
Installation method: slot installation, backplane connection
Working temperature range: -20 ° C to+70 ° C
Appearance specifications: Standard PCB board with gold finger plug
Functional Features
The core function of a static regulator is to achieve static regulation of voltage, current, and frequency in the system, replacing traditional mechanical regulating components;
Fast response: using semiconductor amplification and control components to achieve millisecond level rapid adjustment;
Strong stability: capable of long-term continuous operation in high-frequency switching control systems, with voltage/current closed-loop regulation function;
Control logic integration: embedded with key logic, operation, and comparison circuits to achieve feedback control closed-loop;
Anti interference design: equipped with input signal filtering, overvoltage protection, and short circuit protection functions;
Indication function: Equipped with status indicator lights (LED) for running status and fault diagnosis (supported in some versions).
Application scenarios
GE power plant automatic control system (such as steam turbine generator set)
Control of High Power DC/AC Motor Drive System
GE Mark II/Mark IV Drive and Excitation System
Speed control system for continuous production lines in metallurgy, papermaking, chemical industry, etc
High voltage frequency converter and voltage stabilization control module in inverters
2.產 品 展 示
