GE 193X706AAG02放大器卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X706AAG02 放大器卡技術資料
產品型號：193X706AAG02
產品名稱：放大器卡（Amplifier Card）
制造商：General Electric (GE)
系列：193X 系列工業控制板卡
功能分類：信號放大與增益調節模塊（Signal Amplification and Gain Adjustment）
應用領域：工業自動化系統、數據采集、過程控制等
一、產品功能
GE 193X706AAG02 放大器卡是一款用于提高輸入信號幅度并提供信號增益的模塊。它將輸入的微弱信號放大，以便能夠被系統下游的其他設備或控制單元所接受。該卡廣泛應用于需要信號增益和放大的系統中，如工業自動化控制、傳感器信號處理、數據采集系統等。
主要功能：
輸入信號放大：將低幅度的模擬信號進行放大，以滿足下游設備的輸入要求。
增益調節：提供不同的增益選項，適應多種輸入信號條件。
信號穩定性：提高信號的穩定性，減少噪聲干擾，確保精確控制。
電氣隔離：為防止高電壓或電氣噪聲干擾，提供輸入與輸出的電氣隔離。
二、主要技術參數
| 參數項 | 說明描述 |
|---|---|
| 輸入信號類型 | 模擬信號，如電壓、電流信號，常見為 0-10V、4-20mA 等 |
| 輸出信號類型 | 放大后的模擬信號，通常為 0-10V 或其他標準電壓輸出 |
| 放大增益 | 可調增益，通常提供多個增益設置選項，如 1x、10x、100x 等 |
| 輸入輸出隔離 | 提供輸入與輸出之間的電氣隔離，防止電氣噪聲與干擾傳遞 |
| 電源需求 | ±15V DC 或 24V DC，具體依照系統電源標準 |
| 信號帶寬 | 適用于工業應用的寬帶信號放大，確保信號準確傳遞 |
| 工作溫度范圍 | 通常為 -40°C 到 +85°C，適合各種工業環境使用 |
| 安裝方式 | 插卡式，適配 GE 193X 系列控制機架或控制系統框架 |
| 接口類型 | 一般采用端子連接或金屬插針接口，用于連接外部傳感器和設備 |
| 卡片尺寸 | 標準 GE 插卡式模塊尺寸，符合 193X 系列卡片的標準格式 |
英文資料：
GE 193X706AAG02 amplifier card technical data
Product model: 193X706AAG02
Product Name: Amplifier Card
Manufacturer: General Electric (GE)
Series: 193X series industrial control board
Function classification: Signal Amplification and Gain Adjustment Module
Application areas: Industrial automation systems, data acquisition, process control, etc
1、 Product Features
The GE 193X706AAG02 amplifier card is a module used to increase input signal amplitude and provide signal gain. It amplifies the weak input signal so that it can be accepted by other downstream devices or control units in the system. This card is widely used in systems that require signal gain and amplification, such as industrial automation control, sensor signal processing, data acquisition systems, etc.
Main functions:
Input signal amplification: Amplify low amplitude analog signals to meet the input requirements of downstream devices.
Gain adjustment: Provides different gain options to adapt to various input signal conditions.
Signal stability: Improve signal stability, reduce noise interference, and ensure precise control.
Electrical isolation: To prevent interference from high voltage or electrical noise, provide electrical isolation between input and output.
2、 Main technical parameters
Parameter item description
The input signal type is analog signal, such as voltage, current signal, commonly 0-10V, 4-20mA, etc
The output signal type is an amplified analog signal, usually ranging from 0-10V or other standard voltage outputs
Amplification gain adjustable gain, usually providing multiple gain setting options such as 1x, 10x, 100x, etc
Input/output isolation provides electrical isolation between input and output, preventing the transmission of electrical noise and interference
Power requirement ± 15V DC or 24V DC, according to the system power standard
Signal bandwidth is suitable for broadband signal amplification in industrial applications, ensuring accurate signal transmission
The working temperature range is usually -40 ° C to+85 ° C, suitable for various industrial environments
Installation method plug-in card, compatible with GE 193X series control rack or control system framework
The interface type generally adopts terminal connection or metal pin interface, which is used to connect external sensors and devices
Card size standard GE plug-in module size, in accordance with the standard format of 193X series cards
