GE 193X708AAG02發電機板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X708AAG02 發電機板技術資料
產品型號：193X708AAG02
產品名稱：發電機板（Generator Control Board）
制造商：General Electric (GE)
系列：193X 系列工業控制板卡
功能分類：發電機控制與保護模塊（Generator Control and Protection）
應用領域：發電機組控制、發電廠自動化、能源管理系統等
一、產品功能
GE 193X708AAG02 發電機板主要用于發電機的自動控制、調節以及保護。在發電機系統中，它提供了對電壓、頻率、功率等參數的實時控制和調節，并能夠?qū)崿F(xiàn)對設備的故障檢測和保護。該板卡通過與發電機控制系統的緊密協作，確保發電機的穩定運行，并在出現異常情況下進行及時報警和停機保護，防止設備損壞。
主要功能：
電壓調節：通過對發電機輸出電壓的實時調節，確保電力系統的穩定性。
頻率控制：調節發電機的轉速和輸出頻率，以符合電網要求。
功率調節：根據負載需求調節發電機的輸出功率，確保發電機高效運行。
發電機保護：實時監控發電機的運行狀態，包括溫度、電流、電壓等參數，提供過載、過熱、短路等保護。
遠程監控：支持與遠程監控系統連接，便于集中監控多個發電機組的運行狀態。
報警與故障診斷：當發電機出現故障或工作狀態異常時，自動報警并進行故障診斷。
二、主要技術參數
| 參數項 | 說明描述 |
|---|---|
| 控制功能 | 自動電壓調節、頻率控制、功率調節 |
| 輸入信號類型 | 電流、電壓、溫度等模擬信號輸入 |
| 輸出信號類型 | 電壓、電流、頻率等控制信號輸出 |
| 保護功能 | 過載保護、短路保護、過溫保護、低頻率/高頻率保護等 |
| 工作電壓范圍 | 適用的輸入電壓范圍一般為 24V DC 或 48V DC（具體視系統要求而定） |
| 電氣隔離 | 提供輸入與輸出之間的電氣隔離，防止電氣干擾 |
| 工作溫度范圍 | -40°C 到 +85°C，適應各種工業環境 |
| 卡片尺寸 | 標準 GE 插卡式模塊尺寸，符合 193X 系列格式 |
| 安裝方式 | 插卡式，適配 GE 193X 系列控制機架 |
| 通訊接口 | 支持多種工業通訊協議，如 Modbus、Profibus 等 |
| 故障診斷功能 | 內置故障記錄與報警功能，支持故障代碼診斷 |
英文資料：
GE 193X708AAG02 Generator Board Technical Data
Product model: 193X708AAG02
Product Name: Generator Control Board
Manufacturer: General Electric (GE)
Series: 193X series industrial control board
Function classification: Generator Control and Protection Module
Application areas: generator control, power plant automation, energy management systems, etc
1、 Product Features
The GE 193X708AAG02 generator board is mainly used for automatic control, regulation, and protection of generators. In the generator system, it provides real-time control and regulation of parameters such as voltage, frequency, and power, and can achieve fault detection and protection of equipment. This board ensures the stable operation of the generator through close cooperation with the generator control system, and provides timely alarm and shutdown protection in case of abnormal situations to prevent equipment damage.
Main functions:
Voltage regulation: By real-time adjustment of the output voltage of the generator, the stability of the power system is ensured.
Frequency control: Adjust the speed and output frequency of the generator to meet the requirements of the power grid.
Power regulation: Adjust the output power of the generator according to the load demand to ensure efficient operation of the generator.
Generator protection: Real time monitoring of the operating status of the generator, including parameters such as temperature, current, voltage, etc., providing protection against overload, overheating, short circuit, etc.
Remote monitoring: Supports connection with remote monitoring systems for centralized monitoring of the operating status of multiple generator sets.
Alarm and fault diagnosis: When the generator malfunctions or has abnormal working conditions, it will automatically alarm and perform fault diagnosis.
2、 Main technical parameters
Parameter item description
Control functions include automatic voltage regulation, frequency control, and power regulation
Input signal type: Analog signal input such as current, voltage, temperature, etc
Output signal type: Voltage, current, frequency, etc. Control signal output
Protection functions include overload protection, short circuit protection, over temperature protection, low-frequency/high-frequency protection, etc
The applicable input voltage range for the working voltage range is generally 24V DC or 48V DC (depending on system requirements)
Electrical isolation provides electrical isolation between input and output to prevent electrical interference
Working temperature range -40 ° C to+85 ° C, suitable for various industrial environments
Card size standard GE plug-in card module size, in accordance with the 193X series format
Installation method: plug-in card, compatible with GE 193X series control rack
The communication interface supports multiple industrial communication protocols, such as Modbus, Profibus, etc
The fault diagnosis function has built-in fault recording and alarm functions, supporting fault code diagnosis
