GE 193X711ACG03驅動系統模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X711ACG03 驅動系統模塊 - 技術說明
一、產品簡介
193X711ACG03 是 GE（通用電氣）193X 系列中的一款驅動控制模塊，廣泛用于 GE 的電機控制與調速系統中。該模塊負責接收控制信號、輸出驅動指令，并與其他控制、功率和反饋模塊協同運行。
二、主要功能
實現對電動機啟停、調速、方向等運行狀態的控制
接收 PLC 或其他控制系統的指令輸入
輸出放大后的控制信號（如 PWM 或模擬量）到功率驅動器或緩沖放大板
支持閉環反饋控制，與速度或電流傳感器配合使用
提供信號隔離、故障保護等功能，增強系統穩定性
三、技術參數（典型）
電源輸入：±15V / +5V DC（由系統供電）
輸出信號：模擬量控制 / 數字驅動脈沖（依具體電路）
輸入接口：電壓/電流控制信號，TTL 或繼電觸點控制
安裝方式：插卡式結構，適配 GE 193X 背板
工作溫度范圍：-10°C 到 +60°C
模塊尺寸：GE 標準 193X 插板格式
散熱方式：自然風冷或系統風道冷卻
四、常見應用場合
發電站汽輪機調速系統
工業自動化中的大型驅動裝置
GE Speedtronic 控制系統
水泵、風機、壓縮機等電機控制中心
各類直流/交流電機調速與啟?？刂茍?chǎng)合
英文資料：
GE 193X711ACG03 Drive System Module - Technical Description
Brief introduction
193X711ACG03 is a drive control module in the GE 193X series, widely used in GE's motor control and speed regulation systems. This module is responsible for receiving control signals, outputting drive instructions, and operating in conjunction with other control, power, and feedback modules.
2、 Main functions
Realize control over the operation status of the motor, including start stop, speed regulation, and direction
Receive instruction inputs from PLC or other control systems
Output amplified control signals (such as PWM or analog) to power drivers or buffer amplification boards
Support closed-loop feedback control, used in conjunction with speed or current sensors
Provide signal isolation, fault protection and other functions to enhance system stability
3、 Technical parameters (typical)
Power input: ± 15V/+5V DC (powered by the system)
Output signal: analog control/digital drive pulse (depending on the specific circuit)
Input interface: Voltage/current control signal, TTL or relay contact control
Installation method: Plug in card structure, compatible with GE 193X backplane
Working temperature range: -10 ° C to+60 ° C
Module size: GE standard 193X plug-in board format
Cooling method: natural air cooling or system air duct cooling
4、 Common application scenarios
Power plant turbine speed control system
Large scale drive devices in industrial automation
GE Speedtronic Control System
Motor control centers for water pumps, fans, compressors, and other components
Various DC/AC motor speed regulation and start stop control scenarios
2.產 品 展 示
