TRICONEX DI2301 7400208-020 連接模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TRICONEX DI2301 數字輸入連接模塊
部件號：7400208-020
產品類型
數字輸入模塊，通常用于 Triconex 系統中，負責接收來自現場設備的數字輸入信號，并將其傳輸?shù)娇刂葡到y(tǒng)。
主要功能
接收來自現場設備（如限位開關、按鈕、接近開關等）的數字信號。
將這些信號傳送給 Triconex 控制系統用于進一步的處理。
具備強大的信號隔離功能，保證信號的準確性和穩定性。
技術參數
輸入點數：32 個單端輸入或 16 個差分輸入
輸入電壓：24 VDC（常見配置）
輸入類型：支持濕接點和干接點輸入
響應時間：滿足大多數工業控制應用的需求
電氣隔離：輸入通道與系統側有電氣隔離，增強抗干擾能力
工作溫度范圍：-40℃ 至 70℃
存儲溫度范圍：-40℃ 至 85℃
濕度范圍：5% 至 95%（無冷凝）
模塊特點
高可靠性：能夠支持冗余系統架構，確保在故障情況下仍能提供可靠輸入。
多種輸入模式：支持單端輸入和差分輸入，兼容各種現場設備。
電氣隔離：輸入端與控制系統之間有隔離，確保系統的穩定性。
濾波功能：內置信號濾波，減少噪聲干擾，提高信號的準確性。
易于維護：模塊上有狀態指示燈，便于進行故障排除和診斷。
英文資料：
TRICONEX DI2301 Digital Input Connection Module
Part number: 7400208-020
product type
Digital input module, commonly used in Triconex systems, is responsible for receiving digital input signals from field devices and transmitting them to the control system.
major function
Receive digital signals from on-site devices such as limit switches, buttons, proximity switches, etc.
Send these signals to the Triconex control system for further processing.
Equipped with powerful signal isolation function, ensuring the accuracy and stability of signals.
Technical Parameter
Input points: 32 single ended inputs or 16 differential inputs
Input voltage: 24 VDC (common configuration)
Input type: Supports wet contact and dry contact input
Response time: Meet the needs of most industrial control applications
Electrical isolation: The input channel is electrically isolated from the system side to enhance anti-interference capability
Working temperature range: -40 ℃ to 70 ℃
Storage temperature range: -40 ℃ to 85 ℃
Humidity range: 5% to 95% (without condensation)
Module Features
High reliability: capable of supporting redundant system architecture, ensuring reliable input in case of failure.
Multiple input modes: Supports single ended input and differential input, compatible with various field devices.
Electrical isolation: There is isolation between the input terminal and the control system to ensure system stability.
Filtering function: Built in signal filtering reduces noise interference and improves signal accuracy.
Easy to maintain: The module has status indicator lights for easy troubleshooting and diagnosis.
2.產 品 展 示
