TRICONEX DO3401 數字輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
型號：TRICONEX DO3401
類型：數字輸出模塊（Digital Output Module）
用途：用于 Triconex 安全控制系統中，將控制信號以數字形式輸出至現場設備。
模塊功能
TRICONEX DO3401 模塊提供三重冗余的數字輸出能力，支持與工業現場設備（如繼電器、電磁閥、信號燈等）連接。每個輸出通道均具備隔離保護，能確保系統的可靠性與安全性。
技術參數
輸出通道數量：32 點數字輸出
輸出類型：24 VDC，低電平有效（Sink 型輸出）
輸出結構：晶體管輸出（NPN 或 PNP，具體版本決定）
輸出能力：每通道最大支持 0.5 A 電流
輸出電壓范圍：18 ~ 32 VDC（推薦 24VDC）
通道隔離：每通道與系統總線之間具有光電隔離
響應時間：≤ 5 ms（通道延遲）
短路保護：具備通道級短路與過流保護
冗余特性：與 Tricon 三重冗余架構配合運行，每個子模塊冗余同步輸出
狀態監控：支持每通道狀態診斷、失效監控和 LED 狀態指示
模塊識別：支持自動識別與配置，由控制器分配通道地址
結構與連接
安裝方式：插入 TRICONEX 系統背板，配合 DO2401 底座使用
接線接口：連接到底座上的接線端子，由底座將輸出信號引出
狀態指示：面板配有 LED 指示燈，用于顯示每個通道的輸出狀態和模塊健康狀態
英文資料：
Model: TRICONEX DO3401
Type: Digital Output Module
Purpose: Used in Triconex safety control systems to output control signals in digital form to field devices.
Module functionality
The TRICONEX DO3401 module provides triple redundant digital output capability and supports connection with industrial field devices such as relays, solenoid valves, signal lights, etc. Each output channel is equipped with isolation protection to ensure the reliability and safety of the system.
Technical Parameter
Number of output channels: 32 digital outputs
Output type: 24 VDC, low level active (Sink type output)
Output structure: Transistor output (NPN or PNP, depending on the specific version)
Output capability: Each channel supports a maximum current of 0.5 A
Output voltage range: 18~32 VDC (recommended 24VDC)
Channel isolation: Each channel has optoelectronic isolation between it and the system bus
Response time: ≤ 5 ms (channel delay)
Short circuit protection: equipped with channel level short circuit and overcurrent protection
Redundancy feature: Operates in conjunction with the Tricon triple redundancy architecture, with each submodule outputting redundant and synchronized outputs
Status monitoring: supports status diagnosis, failure monitoring, and LED status indication for each channel
Module recognition: supports automatic recognition and configuration, with channel addresses allocated by the controller
Structure and connection
Installation method: Insert the TRICONEX system backplane and use it in conjunction with the DO2401 base
Wiring interface: Connect to the wiring terminal on the base, and the output signal is led out by the base
Status indication: The panel is equipped with LED indicator lights to display the output status of each channel and the health status of the module
2.產 品 展 示
