TRICONEX EPI3382 通訊模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
型號：TRICONEX EPI3382
類型：通信接口模塊（Enhanced Performance Interface, EPI）
產品概述
TRICONEX EPI3382 是一款增強型通信模塊，主要用于 Triconex 安全控制系統與上位機或第三方系統之間的高速數據通信。該模塊支持多種工業通信協議，并具備高性能處理能力和三重冗余同步功能，是分布式控制系統（DCS）、SCADA、歷史數據庫等系統與 Tricon 控制器之間通信的橋梁。
主要功能
實現 Tricon 控制器與外部系統間的數據交換
支持多個通信端口并行工作
可進行多協議數據封裝和格式轉換
提供網絡隔離和故障冗余轉移能力
支持冗余對等通信模塊協同運行，提高系統穩定性
技術參數
通信端口：最多支持 2 個 10/100 Mbps Ethernet 端口
協議支持（根據配置）：
Modbus TCP/IP
Modbus RTU/ASCII（需適配）
TCP/UDP 定制協議
OPC（通過服務器）
內部處理器：高性能嵌入式處理器，專用于數據通信任務
系統集成：可與 Tricon 系統主控架構配套使用，通過系統背板通信
模塊地址識別：自動識別與配置，無需人工跳線
狀態指示：面板帶有通信狀態和模塊狀態 LED 指示燈
熱插拔功能：支持在線插拔更換模塊
英文資料：
Model: TRICONEX EPI3382
Type: Enhanced Performance Interface (EPI) communication interface module
product overview
The Triconex EPI3382 is an enhanced communication module primarily used for high-speed data communication between Triconex safety control systems and host computers or third-party systems. This module supports multiple industrial communication protocols and has high-performance processing capabilities and triple redundancy synchronization functions. It serves as a bridge for communication between distributed control systems (DCS), SCADA, historical databases, and Tricon controllers.
major function
Realize data exchange between Tricon controller and external systems
Support parallel operation of multiple communication ports
Capable of multi protocol data encapsulation and format conversion
Provide network isolation and fault redundancy transfer capability
Support collaborative operation of redundant peer-to-peer communication modules to improve system stability
Technical Parameter
Communication ports: Supports up to 2 10/100 Mbps Ethernet ports
Protocol support (based on configuration):
Modbus TCP/IP
Modbus RTU/ASCII (adaptation required)
TCP/UDP custom protocol
OPC (via server)
Internal processor: High performance embedded processor dedicated to data communication tasks
System integration: It can be used in conjunction with the main control architecture of the Tricon system and communicates through the system backplane
Module address recognition: automatic recognition and configuration, no need for manual jumpers
Status indication: The panel is equipped with communication status and module status LED indicators
Hot swappable function: supports online plugging and swapping of modules
2.產 品 展 示
