BENTLY 3500/22 288055-01 瞬態數據接口 PDF資料
1.產 品 資 料 介 紹：
中文資料：
產品名稱
品牌：Bently Nevada（本特利）
模塊型號：3500/22
部件號：288055-01
模塊類型：Transient Data Interface（瞬態數據接口）
模塊概述
BENTLY 3500/22（PN：288055-01）瞬態數據接口模塊 是 3500 系列機械保護系統中的一部分，用于實現系統與外部分析工具之間的高分辨率數據交互。
該模塊的主要作用是將**高速瞬態數據（如振動波形、沖擊事件、啟動/停機數據等）**傳輸?shù)?Bently 的數據采集和分析平臺，如 System 1，便于工程人員進行故障診斷和趨勢分析。
主要功能
實時捕獲和傳輸高分辨率瞬態信號數據
提供關鍵旋轉機械的動態行為監測數據
作為 3500 系統與系統分析軟件之間的數據橋梁
支持開機/停機過程的事件記錄與分析
與 System 1 平臺無縫集成，用于狀態監測與預測性維護
技術參數
數據類型：原始波形、軌跡數據、沖擊響應、關鍵運行事件
采樣能力：高頻率瞬態采集能力（具體頻率依托安裝的前端傳感器與系統配置）
接口類型：
前端與 3500 機架背板連接（數據總線）
后端提供通信端口（用于與服務器、System 1 連接）
支持通道：最多支持多個動態通道的數據同步采集
安裝位置：安裝于 3500 系列機架中，占用標準模塊槽位
固件支持：需配合匹配版本的配置軟件和 System 1 數據平臺
英文資料：
product name
Brand: Bently Nevada
Module model: 3500/22
Part number: 288055-01
Module type: Transient Data Interface
Module Overview
BENTLY 3500/22 (PN: 288055-01) Transient Data Interface Module is a part of the 3500 series mechanical protection system, used to achieve high-resolution data exchange between the system and external analysis tools.
The main function of this module is to transmit high-speed transient data (such as vibration waveforms, impact events, start/stop data, etc.) to Bently's data acquisition and analysis platform, such as System 1, for engineering personnel to perform fault diagnosis and trend analysis.
major function
Real time capture and transmission of high-resolution transient signal data
Provide dynamic behavior monitoring data for key rotating machinery
As a data bridge between the 3500 system and system analysis software
Support event recording and analysis of startup/shutdown processes
Seamless integration with System 1 platform for condition monitoring and predictive maintenance
Technical Parameter
Data types: raw waveform, trajectory data, impulse response, critical operational events
Sampling capability: High frequency transient acquisition capability (specific frequency depends on the installed front-end sensors and system configuration)
Interface type:
Front end connected to 3500 rack backplane (data bus)
Backend provides communication ports (for connecting with servers and System 1)
Support channels: Supports synchronous data collection for up to multiple dynamic channels
Installation location: Installed in the 3500 series rack, occupying standard module slots
Firmware support: requires matching version of configuration software and System 1 data platform
