DEIF OPM-1 輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
DEIF OPM-1 輸出模塊 是 DEIF 公司推出的一款用于發電機組控制系統中的輸出模塊，主要用于處理從控制系統向外部執行設備（如發電機、負載開關、繼電器等）發出的控制信號。以下是該模塊的詳細介紹：
產品名稱
品牌：DEIF
型號：OPM-1
類別：輸出模塊
產品概述
DEIF OPM-1 輸出模塊是 DEIF 發電機組自動化系統中的一部分，旨在提供控制輸出功能。通過該模塊，控制系統可以輸出控制信號來驅動外部設備或執行器。OPM-1 模塊支持多種輸出方式，包括數字輸出、模擬輸出等，并可以與多種 DEIF 系列控制系統和模塊配合使用。
主要功能
數字輸出：支持數字信號輸出，可以直接控制繼電器、斷路器、啟停信號等。
模擬輸出：提供模擬電壓或電流信號，用于調節負載或其他設備的運行狀態。
遠程控制能力：OPM-1 可通過網絡與遠程監控系統進行通信，實現遠程控制和管理。
可靠性高：具有過載保護和短路保護功能，確保在各種工況下穩定運行。
易于集成：與 DEIF 系列其他模塊兼容，可以方便地集成進復雜的發電機組控制系統中。
技術規格
輸出類型：數字輸出（繼電器驅動、開關控制）、模擬輸出（電流、電壓）
輸出電流：通常為 0-1A（數字輸出），0-20mA 或 0-10V（模擬輸出），具體依據模塊配置
工作電壓：支持 24V DC 或其他電壓輸入，具體根據系統要求而定
工作溫度范圍：-20°C 到 +70°C
防護等級：一般為 IP20，適合安裝于控制柜內部
安裝方式：可在標準 19 英寸機架中安裝，或根據系統需求進行定制安裝
英文資料：
The DEIF OPM-1 output module is an output module developed by DEIF company for use in generator control systems. It is mainly used to process control signals sent from the control system to external executing devices such as generators, load switches, relays, etc. The following is a detailed introduction to the module:
product name
Brand: DEIF
Model: OPM-1
Category: Output Module
product overview
The DEIF OPM-1 output module is a part of the DEIF generator automation system, designed to provide control output functionality. Through this module, the control system can output control signals to drive external devices or actuators. The OPM-1 module supports multiple output modes, including digital output, analog output, etc., and can be used in conjunction with various DEIF series control systems and modules.
major function
Digital output: Supports digital signal output and can directly control relays, circuit breakers, start stop signals, etc.
Analog output: Provides analog voltage or current signals to regulate the operating status of loads or other devices.
Remote control capability: OPM-1 can communicate with remote monitoring systems through the network to achieve remote control and management.
High reliability: equipped with overload protection and short circuit protection functions, ensuring stable operation under various working conditions.
Easy to integrate: Compatible with other modules in the DEIF series, it can be easily integrated into complex generator control systems.
technical specifications
Output types: digital output (relay driven, switch controlled), analog output (current, voltage)
Output current: usually 0-1A (digital output), 0-20mA or 0-10V (analog output), depending on module configuration
Working voltage: Supports 24V DC or other voltage inputs, depending on system requirements
Working temperature range: -20 ° C to+70 ° C
Protection level: generally IP20, suitable for installation inside control cabinets
Installation method: It can be installed in a standard 19 inch rack or customized according to system requirements
2.產 品 展 示
