FOXBORO FDC280 RH101FQ 現場設備控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
基本信息
產品名稱：FDC280 現場設備控制器
完整型號：FDC280 RH101FQ
制造商：FOXBORO（?？怂共_，施耐德電氣旗下品牌）
產品類別：現場控制器 / DCS 控制單元
應用領域：過程控制系統、分布式控制系統（DCS）、煉油、化工、電力等工業自動化場合
核心功能
集成控制與通信功能
集成了控制算法處理、I/O 數據采集、現場通信、診斷功能于一體，作為 DCS 系統的控制中樞。
多協議通信支持
支持 FOUNDATION Fieldbus（FF）、HART、Modbus 等通信協議，可與智能變送器、執行器等設備直接通信。
冗余支持（可選）
支持冗余配置，具備雙主控通道功能，實現高可用性與系統熱切換。
本地控制邏輯運行
現場獨立運行控制策略，即便與主系統通信中斷也能維持核心控制任務。
工程配置與遠程管理
配合 Foxboro 的控制系統軟件（如 Foxboro Evo 或 I/A Series）進行工程組態、監控和遠程診斷。
技術參數（典型）
| 項目 | 參數說明 |
|---|---|
| 電源電壓 | 24V DC（冗余供電支持） |
| 通信接口 | Fieldbus、Modbus、以太網等 |
| 數據處理能力 | 多任務并發、快速響應周期控制 |
| 控制策略 | 支持 PID、順序控制、邏輯控制等 |
| 環境溫度范圍 | -20°C 到 +70°C（工業級） |
| 安裝方式 | 機架式或現場壁掛安裝 |
| 防護等級 | 通常為 IP20（視安裝箱體而定） |
| 軟件支持 | Foxboro Control Software、Evo |
英文資料：
Basic information
Product Name: FDC280 Field Equipment Controller
Complete model: FDC280 RH101FQ
Manufacturer: FOXBORO (Foxboro, a brand under Schneider Electric)
Product Category: On site Controller/DCS Control Unit
Application areas: Process control systems, distributed control systems (DCS), industrial automation applications such as refining, chemical, and power
Core functions
Integrated control and communication functions
Integrated control algorithm processing, I/O data acquisition, on-site communication, and diagnostic functions, serving as the control center of the DCS system.
Multi protocol communication support
Supports communication protocols such as FOUNDATION Fieldbus (FF), HART, Modbus, etc., and can directly communicate with smart transmitters, actuators, and other devices.
Redundancy support (optional)
Support redundant configuration, with dual main control channel function, achieving high availability and system hot switching.
Local control logic operation
On site independent operation control strategy can maintain core control tasks even if communication with the main system is interrupted.
Engineering Configuration and Remote Management
Cooperate with Foxboro's control system software (such as Foxboro Evo or I/A Series) for engineering configuration, monitoring, and remote diagnosis.
Technical parameters (typical)
Project parameter description
Power supply voltage 24V DC (redundant power supply support)
Communication interfaces such as Fieldbus, Modbus, Ethernet, etc
Data processing capability, multitasking concurrency, fast response cycle control
Control strategy supports PID, sequential control, logic control, etc
Environmental temperature range -20 ° C to+70 ° C (industrial grade)
Installation method: rack mounted or on-site wall mounted installation
The protection level is usually IP20 (depending on the installation box)
Software support Foxboro Control Software, Evo
2.產 品 展 示
