B&R 8LSA35.E2060D000-0 伺服電機 PDF資料
1.產 品 資 料 介 紹：
中文資料：
B&R 8LSA35.E2060D000-0 是一款工業用三相同步伺服電機，屬于 B&R 的 8LS 系列，專為高性能運動控制系統設計，具有高速度、高精度、高響應特性，適用于數控機床、包裝機械、機器人和自動化生產線等應用場合。
基本參數：
型號：8LSA35.E2060D000-0
類型：三相同步伺服電機
額定轉速：6000 rpm
持續扭矩：2.3 Nm（堵轉扭矩）
電壓等級：約 560V DC（與 B&R ACOPOS 驅動系統配合使用）
編碼器：多圈 EnDat 編碼器（32線制，用于高精度位置反饋）
制動器：無制動器（可選帶制動版本）
軸類型：光軸
安裝方式：法蘭安裝
防護等級：IP64（防塵防水濺）
冷卻方式：自然冷卻
主要特點：
高速響應，適用于高速高精定位
精密位置反饋，配合 B&R 驅動器自動識別電機參數
支持單電纜連接技術，簡化安裝布線
結構緊湊，適合空間受限的設備安裝
與 B&R Automation Studio 編程環境完全集成，便于系統調試與維護
英文資料：
B&R 8LSA35. E2060D000-0 is an industrial three-phase synchronous servo motor belonging to B&R's 8LS series. It is designed for high-performance motion control systems and has high speed, high precision, and high response characteristics. It is suitable for applications such as CNC machine tools, packaging machinery, robots, and automated production lines.
Basic parameters:
Model: 8LSA35,E2060D000-0
Type: Three phase synchronous servo motor
Rated speed: 6000 rpm
Continuous torque: 2.3 Nm (locked rotor torque)
Voltage level: Approximately 560V DC (used in conjunction with B&R ACOPOS drive system)
Encoder: Multi turn EnDat encoder (32 wire system, used for high-precision position feedback)
Brake: No brake (optional with brake version)
Axis type: Optical axis
Installation method: flange installation
Protection level: IP64 (dustproof, waterproof, splash proof)
Cooling method: natural cooling
Main features:
High speed response, suitable for high-speed and high-precision positioning
Precise position feedback, combined with B&R driver to automatically identify motor parameters
Support single cable connection technology to simplify installation and wiring
Compact structure, suitable for installation of equipment with limited space
Fully integrated with B&R Automation Studio programming environment for easy system debugging and maintenance
2.產 品 展 示
