Woodward 5501-412模擬 I/O 模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Woodward 5501-412 是一款用于工業控制系統中的模擬 I/O 模塊，主要集成于 Woodward 的控制器平臺（如 MicroNet、2301E 或 Atlas 系列）中，承擔模擬信號的輸入與輸出接口功能，適用于精密控制與過程監測任務。
一、產品基本信息：
型號：5501-412
類型：模擬輸入/輸出（Analog I/O）模塊
品牌：Woodward
兼容平臺：Woodward 控制系統（如 MicroNet 或 Atlas 系列）
二、主要功能與特性：
模擬輸入（AI）功能：
支持多個通道的模擬電壓或電流信號輸入
典型輸入范圍：0–5V、0–10V、4–20 mA 等（視具體配置）
可用于采集傳感器、變送器等設備的信號，如壓力、溫度、流量等過程變量
模擬輸出（AO）功能：
提供多個通道的模擬輸出控制
用于向執行器、變頻器、模擬儀表等發送控制信號
輸出范圍通常為 0–5V、0–10V、或 4–20mA（可配置）
精度與穩定性：
高分辨率 A/D 與 D/A 轉換器
抗噪能力強，適合在工業現場惡劣環境中運行
提供隔離保護，防止信號干擾或設備損壞
診斷與狀態監控：
集成自診斷功能
支持狀態 LED 顯示通道運行狀態與故障信息
可通過系統軟件進行在線監控和配置
英文資料：
Woodward 5501-412 is an analog I/O module used in industrial control systems, mainly integrated into Woodward's controller platforms (such as MicroNet, 2301E, or Atlas series), responsible for the input and output interface functions of analog signals, suitable for precision control and process monitoring tasks.
1、 Product basic information:
Model: 5501-412
Type: Analog I/O module
Brand: Woodward
Compatible platform: Woodward control system (such as MicroNet or Atlas series)
2、 Main functions and features:
Analog input (AI) function:
Supports multiple channels of analog voltage or current signal input
Typical input range: 0-5V, 0-10V, 4-20 mA, etc. (depending on specific configuration)
Can be used to collect signals from sensors, transmitters, and other devices, such as process variables such as pressure, temperature, flow rate, etc
Analog Output (AO) Function:
Provide analog output control for multiple channels
Used to send control signals to actuators, frequency converters, analog instruments, etc
The output range is usually 0-5V, 0-10V, or 4-20mA (configurable)
Accuracy and stability:
High resolution A/D and D/A converters
Strong noise resistance, suitable for operation in harsh industrial environments
Provide isolation protection to prevent signal interference or equipment damage
Diagnosis and status monitoring:
Integrated self diagnostic function
Support status LED display of channel operation status and fault information
Online monitoring and configuration can be carried out through system software
