MAS PD5010-LCD 接口模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
MAS PD5010-LCD 接口模塊 是一款集成顯示功能的通信與狀態接口模塊，通常用于工業自動化、電力監控或過程控制系統中。以下是該模塊的詳細介紹：
一、產品概述：
產品型號：PD5010-LCD
品牌：MAS（可能為 Monitoring and Automation Systems 的縮寫）
類型：LCD 顯示型接口模塊 / 通信終端
主要功能：狀態顯示、數據通信、系統診斷接口
二、主要功能與特點：
| 功能類別 | 描述 |
|---|---|
| 液晶顯示屏 | 帶有 LCD 顯示，用戶可查看設備狀態、地址、運行參數、故障代碼等信息。 |
| 通信接口 | 支持常見通信協議（如 RS-232、RS-485、Modbus RTU），用于與主站或上位系統通信。 |
| 人機交互 | 內建按鍵或觸控區域，可進行簡單的本地參數設定或查詢操作。 |
| 模塊地址設定 | 可手動或通過軟件設定通信地址，適用于多從站系統。 |
| 診斷與監控 | 提供系統運行、異常、通訊狀態等可視化反饋，便于運維人員排查問題。 |
三、典型技術參數（視版本而定）：
工作電壓：24V DC（或依據具體型號）
接口類型：RS-485/RS-232，可選 Ethernet（部分型號）
通訊協議：Modbus RTU、ASCII 或定制協議
顯示形式：段式 LCD 或圖形 LCD（多行為主）
防護等級：一般為 IP20~IP40（用于柜內）
工作環境：-10°C ~ +55°C，適應工業現場使用
英文資料：
The MAS PD5010-LCD interface module is a communication and status interface module that integrates display functions, typically used in industrial automation, power monitoring, or process control systems. The following is a detailed introduction to the module:
1、 Product Overview:
Product model: PD5010-LCD
Brand: MAS (possibly an abbreviation for Monitoring and Automation Systems)
Type: LCD display interface module/communication terminal
Main functions: status display, data communication, system diagnostic interface
2、 Main functions and features:
Functional category description
The LCD screen is equipped with an LCD display, allowing users to view device status, address, operating parameters, fault codes, and other information.
The communication interface supports common communication protocols such as RS-232, RS-485, Modbus RTU, and is used for communication with the main station or upper system.
Built in buttons or touch areas for human-computer interaction, allowing for simple local parameter settings or query operations.
The module address setting can be manually or through software to set the communication address, suitable for multi slave systems.
Diagnosis and monitoring provide visual feedback on system operation, abnormalities, communication status, etc., making it easy for operation and maintenance personnel to troubleshoot problems.
3、 Typical technical parameters (depending on version):
Working voltage: 24V DC (or depending on specific model)
Interface type: RS-485/RS-232, optional Ethernet (some models)
Communication protocol: Modbus RTU, ASCII or custom protocol
Display format: Segmented LCD or graphic LCD (with multiple rows as the main display)
Protection level: generally IP20~IP40 (for use inside cabinets)
Working environment: -10 ° C~+55 ° C, suitable for industrial site use
