TEL Tokyo Electron 381-642277-4限制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 381-642277-4 限制板
產品類別：限制板 / 接口板（tVME-UIO/BS）
所屬系統：多用于 VME 總線架構的半導體設備控制系統中
典型設備：光刻機、刻蝕機、CVD/PVD 薄膜沉積設備、晶圓清洗系統等
產品應用領域詳解：
1. 半導體設備控制模塊的接口管理
該限制板作為接口通道板，用于控制器（如主CPU或處理器板）與各種執行器、傳感器之間的數據和控制信號連接，是設備邏輯控制鏈條中的橋梁。
2. I/O 接口擴展與集成
在VME總線架構中，381-642277-4限制板用于擴展多個I/O信號通道。它可集成多種接口信號（模擬量、開關量等），確保系統具備靈活、可擴展的信號處理能力。
3. 自動化工藝控制
廣泛用于半導體制程中的氣體流量、溫控、真空腔壓等工藝參數的精密控制，作為自動化工藝單元中的標準接口設備。
4. 設備間通信協調
用于不同子系統間的數據同步和命令傳輸，例如主控板與各功能模塊（閥門控制、加熱單元、電機驅動等）之間的通信橋梁。
5. 系統維護與故障定位支持
由于模塊化設計，該限制板在設備維護時便于快速更換。它還能協助定位信號異常或通信中斷等故障，提高設備可維護性。
6. 抗干擾與工業穩定性
該限制板為工業級設計，具備高抗電磁干擾能力，適合在半導體設備嚴苛的運行環境中長期工作，確保設備運行穩定性。
英文資料：
TEL Tokyo Electron 381-642277-4 restriction board
Product Category: Restrictive Board/Interface Board (tTME-UIO/BS)
System: Commonly used in semiconductor equipment control systems with VME bus architecture
Typical equipment: lithography machine, etching machine, CVD/PVD thin film deposition equipment, wafer cleaning system, etc
Detailed explanation of product application areas:
1. Interface management of semiconductor equipment control module
This restriction board serves as an interface channel board for connecting data and control signals between controllers (such as main CPU or processor boards) and various actuators and sensors, and is a bridge in the device logic control chain.
2. I/O interface expansion and integration
In the VME bus architecture, the 381-642277-4 restriction board is used to expand multiple I/O signal channels. It can integrate multiple interface signals (analog, switch, etc.) to ensure that the system has flexible and scalable signal processing capabilities.
3. Automated process control
Widely used for precise control of process parameters such as gas flow rate, temperature control, and vacuum chamber pressure in semiconductor processes, as a standard interface device in automated process units.
4. Communication and coordination between devices
Used for data synchronization and command transmission between different subsystems, such as the communication bridge between the main control board and various functional modules (valve control, heating unit, motor drive, etc.).
5. System maintenance and fault location support
Due to its modular design, this restriction board is easy to replace quickly during equipment maintenance. It can also assist in locating faults such as signal abnormalities or communication interruptions, improving equipment maintainability.
6. Anti interference and industrial stability
This restriction board is designed for industrial use and has high resistance to electromagnetic interference. It is suitable for long-term operation in the harsh operating environment of semiconductor equipment, ensuring the stability of equipment operation.
2.產 品 展 示
