TEL Tokyo Electron ES1D80-001291-13電源供應器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
產品名稱
TEL Tokyo Electron ES1D80-001291-13 電源供應器
（對應 OEM 原廠型號：Sanken MLT-DCB0X5 / DCBOX5）
主要功能
這是一款多路直流輸出電源模塊，為TEL半導體設備內部各類電控系統提供穩定的電源支持，支持多種電壓軌輸出，廣泛用于高精度控制和驅動電路中。
典型技術參數（參考值）
輸入電壓：90–110 VAC，約6.5 A
輸出電壓通道：
+5V / 10A
+15V / 1.7A
–15V / 2A
+24V / 4.1A
+12V / 3A
這些輸出用于為控制板、信號板、執行單元等提供所需不同電壓等級。
產品應用領域
1. 等離子蝕刻設備供電系統
廣泛應用于TEL的等離子蝕刻設備（如 Unity II U2-855DD 系列）中，為控制系統、RF模塊、真空接口、腔體控制等關鍵組件提供多路電源。
2. 設備控制板與VME總線系統供電
為設備中控制主板、輸入輸出模塊（I/O）、接口板、邏輯處理單元等多個子系統提供各自所需電壓，滿足復雜電路同時供電的需求。
3. 傳感器與執行器模塊驅動
用于為各類精密傳感器、閥門控制器、伺服單元、電磁驅動器等模塊供電，確保工藝控制的實時性和精確性。
4. 工藝控制系統與安全監測供電
為與溫度、氣壓、真空、流量控制相關的模塊提供穩定電源，支持對設備運行狀態的實時監測和控制。
5. 設備維護與模塊替換兼容性強
其模塊化、多電壓輸出設計，便于設備在故障更換、升級擴展中快速對接，減少系統停機時間，提高維護效率。
英文資料：
product name
TEL Tokyo Electron ES1D80-001291-13 Power Supply Unit
(Corresponding OEM original model: Sanken MLT-DCB0X5/DCBOX5)
major function
This is a multi-channel DC output power module that provides stable power support for various electronic control systems inside TEL semiconductor equipment. It supports multiple voltage rail outputs and is widely used in high-precision control and drive circuits.
Typical technical parameters (reference values)
Input voltage: 90-110 VAC, approximately 6.5 A
Output voltage channel:
+5V / 10A
+15V / 1.7A
–15V / 2A
+24V / 4.1A
+12V / 3A
These outputs are used to provide different voltage levels required for control boards, signal boards, execution units, etc.
Product application areas
1. Power supply system for plasma etching equipment
Widely used in TEL's plasma etching equipment (such as the Unity II U2-855DD series), it provides multiple power sources for key components such as control systems, RF modules, vacuum interfaces, and chamber control.
2. Power supply for equipment control board and VME bus system
To provide the required voltage for multiple subsystems such as the control motherboard, input/output module (I/O), interface board, and logic processing unit in the device, meeting the simultaneous power supply needs of complex circuits.
3. Sensor and actuator module drivers
Used to supply power to various precision sensors, valve controllers, servo units, electromagnetic drivers, and other modules, ensuring real-time and accurate process control.
4. Process control system and safety monitoring power supply
Provide stable power supply for modules related to temperature, air pressure, vacuum, and flow control, and support real-time monitoring and control of equipment operating status.
5. Strong compatibility between equipment maintenance and module replacement
Its modular and multi voltage output design facilitates rapid integration of equipment during fault replacement, upgrade, and expansion, reducing system downtime and improving maintenance efficiency.
2.產 品 展 示
