TEL Tokyo Electron 2L08-00005-12傳感器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 2L08-00005-12 傳感器模塊
類型：傳感器組件 / Sensor Module
制造商：Tokyo Electron Ltd.（TEL）
一、產品功能概述
該模塊是 TEL 半導體設備中的一種 專用傳感器接口或集成傳感器單元，其作用通常為：
監測設備內部的某種關鍵物理參數（如溫度、壓力、流量、位置、電壓等）
將模擬信號或數字信號反饋至主控系統進行實時調節或安全聯鎖
用于閉環控制系統，配合執行器精確調節設備運行狀態
具備模塊化封裝，便于在特定腔體或系統模塊內獨立安裝和替換
二、典型應用領域
1. 真空腔體管理系統（Etcher / CVD）
檢測腔體內的氣壓、溫度或氣體流速
反饋數據用于調節真空泵、MFC（質量流量控制器）、加熱器等設備
2. 晶圓傳輸系統（Wafer Handling / Load Port）
檢測機械臂或升降平臺的位置、速度、到位狀態
確保晶圓搬運過程中動作精準無誤
3. 液體或化學品供應系統（Wet Station / Cleaning）
檢測液體溫度、壓力、流量等
保障清洗液穩定供應，避免干涸、過壓或溫控異常
4. 溫控模塊（Thermal Management）
實時監測加熱平臺、冷卻板等裝置的溫度分布
配合PID控制器調整電流或流體循環系統
英文資料：
TEL Tokyo Electron 2L08-00005-12 Sensor Module
Type: Sensor Module
Manufacturer: Tokyo Electron Ltd. (TEL)
1、 Product Function Overview
This module is a dedicated sensor interface or integrated sensor unit in TEL semiconductor equipment, typically used for:
Monitor a key physical parameter inside the device (such as temperature, pressure, flow rate, position, voltage, etc.)
Feedback analog or digital signals to the main control system for real-time adjustment or safety interlocking
Used for closed-loop control systems, in conjunction with actuators to accurately adjust the operating status of equipment
Equipped with modular packaging, it is easy to independently install and replace within specific cavities or system modules
2、 Typical application areas
1. Vacuum chamber management system (Etcher/CVD)
Detect the pressure, temperature, or gas flow rate inside the chamber
Feedback data is used to adjust equipment such as vacuum pumps, MFCs (Mass Flow Controllers), heaters, etc
2. Wafer Handling/Load Port System
Detect the position, speed, and in place status of the robotic arm or lifting platform
Ensure precise and error free movements during wafer handling
3. Liquid or chemical supply system (Wet Station/Cleaning)
Detect liquid temperature, pressure, flow rate, etc
Ensure stable supply of cleaning solution, avoid drying up, overpressure or abnormal temperature control
4. Thermal Management Module
Real time monitoring of temperature distribution of heating platform, cooling plate and other devices
Adjust current or fluid circulation system in conjunction with PID controller
2.產 品 展 示
