TEL Tokyo Electron UPC-T0089A-11連接器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron UPC-T0089A-11 連接器模塊
類別：連接器模塊（Connector Module）
制造商：Tokyo Electron Ltd.（TEL）
一、產品功能概述
該連接器模塊主要用于半導體制造設備中，實現設備內部各電子模塊之間的可靠電氣連接。其功能包括：
提供多針多通道的電信號和控制信號接口
連接主控板、接口板、傳感器模塊、驅動器等子模塊
支持高速數據傳輸和低電阻電源連接
結構緊湊，方便模塊化安裝和快速拆裝維護
二、典型應用領域
設備內部信號總線連接
作為各控制模塊之間的標準接口，實現數據和控制信號的傳遞
氣體流量控制與閥門驅動系統
連接質量流量控制器（MFC）與主控板，實現精確氣體配比控制
機械臂與搬運模塊
驅動機械手執行動作的電氣接口，保障信號穩定與動作精確
真空腔體監控系統
連接傳感器、閥門及監控單元，確保真空系統安全運行
三、產品特點
高密度、多針腳設計，支持復雜信號布線
工業級耐用設計，適應高潔凈度和高穩定性要求
可靠的插拔結構，支持反復拆裝
兼容TEL多種設備控制架構，便于系統集成和維護
英文資料：
TEL Tokyo Electron UPC-T0089A-11 connector module
Category: Connector Module
Manufacturer: Tokyo Electron Ltd. (TEL)
1、 Product Function Overview
This connector module is mainly used in semiconductor manufacturing equipment to achieve reliable electrical connections between various electronic modules inside the equipment. Its functions include:
Provide multi pin and multi-channel electrical and control signal interfaces
Connect sub modules such as the main control board, interface board, sensor module, driver, etc
Supports high-speed data transmission and low resistance power connection
Compact structure, convenient modular installation and quick disassembly and maintenance
2、 Typical application areas
Internal signal bus connection of the device
As a standard interface between various control modules, it enables the transmission of data and control signals
Gas flow control and valve drive system
Connect the Mass Flow Controller (MFC) to the main control board to achieve precise gas ratio control
Mechanical arm and handling module
The electrical interface that drives the robotic arm to perform actions ensures stable signals and precise movements
Vacuum chamber monitoring system
Connect sensors, valves, and monitoring units to ensure safe operation of the vacuum system
3、 Product Features
High density, multi pin design, supporting complex signal wiring
Industrial grade durable design, suitable for high cleanliness and stability requirements
Reliable plug-in structure, supporting repeated disassembly and assembly
Compatible with multiple TEL device control architectures, facilitating system integration and maintenance
2.產 品 展 示
3.其他產品
4.其他英文產品
ASEA 2668 180-291 slot control
| 710-404420-00 | 193X741EAG01 | F31X171TMAAFG2 |
| 710-404228-00 | 193X803BBG03 | 710-300015-01 |
| 710-404208-00 | 531X121PCRACG1 | 073-805314-00 |
| 710-404146-00 | 03-137064-00 | 740-612539-000 |
| 710-401536-00 | 531X102CCHAHM2 | F31X139APMABG2 |
| 710-401249-00 | 531X111PSHAJG1 | 710-611534-000 |
| 710-400535-00 | 193X728ABG01 | F31X139APMASG2 |
