TEL Tokyo Electron CT5085-430221-15旋轉器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron CT5085-430221-15 旋轉器
類別：機械旋轉組件 / Rotator
制造商：Tokyo Electron Ltd.（TEL）
一、產品功能概述
該旋轉器是一種用于半導體制造設備中的精密機械執行部件，主要負責：
精確控制晶圓或相關工件的旋轉位置和速度
配合機械臂、傳感器實現晶圓對位、搬運、翻轉等動作
保障旋轉過程的平穩性與重復定位精度
支持與驅動器和控制系統協同工作，實現閉環控制
二、典型應用領域
晶圓傳輸和裝載系統
在 Loadport、Transfer Module 或 Robot 手臂中實現晶圓旋轉
便于晶圓與設備接口的對準和放置
光刻與曝光設備
控制晶圓旋轉，實現多角度曝光或?qū)?zhǔn)
保證圖案精準疊加與位置校正
刻蝕與沉積工藝設備
旋轉晶圓以實現均勻刻蝕或沉積效果
控制旋轉速度，保證工藝穩定性
檢測與測試設備
旋轉工件進行多角度檢測或光學測量
三、產品技術特性
高精度旋轉軸承，確保平滑無間隙旋轉
支持多速率調節及可編程控制
結構緊湊，便于集成于設備狹小空間
兼容工業標準驅動接口，可與伺服電機等執行器配合使用
設計滿足潔凈室和高穩定性環境要求
英文資料：
TEL Tokyo Electron CT5085-430221-15 rotator
Category: Mechanical Rotating Components/Rotator
Manufacturer: Tokyo Electron Ltd. (TEL)
1、 Product Function Overview
This rotator is a precision mechanical actuator used in semiconductor manufacturing equipment, mainly responsible for:
Accurately control the rotational position and speed of wafers or related workpieces
Cooperate with robotic arms and sensors to achieve wafer alignment, handling, flipping, and other actions
Ensure the smoothness and repeated positioning accuracy of the rotation process
Support collaborative work with drivers and control systems to achieve closed-loop control
2、 Typical application areas
Wafer transfer and loading system
Realize wafer rotation in Loadport, Transfer Module, or Robot arm
Easy alignment and placement of wafer and equipment interfaces
Lithography and exposure equipment
Control wafer rotation to achieve multi angle exposure or alignment
Ensure precise pattern overlay and position correction
Etching and deposition process equipment
Rotate the wafer to achieve uniform etching or deposition effect
Control rotation speed to ensure process stability
Testing and Inspection Equipment
Rotating workpieces for multi angle detection or optical measurement
3、 Product Technical Characteristics
High precision rotating bearings ensure smooth and seamless rotation
Support multi rate regulation and programmable control
Compact structure, easy to integrate into narrow spaces of equipment
Compatible with industrial standard driver interfaces, can be used in conjunction with servo motors and other actuators
Design to meet the requirements of clean rooms and high stability environments
2.產 品 展 示
