TEL Tokyo Electron EPC-T0091A-11輸入輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、功能概述
EPC-T0091A-11 輸入輸出模塊是 TEL 半導體設備中控制系統的關鍵部件，主要用于在主控系統與設備執行/檢測元件之間傳遞和轉換信號。其核心功能包括：
接收來自傳感器的各種輸入信號（如光電、限位、溫度、壓力等）
向執行器輸出控制信號（如繼電器、電磁閥、馬達驅動器等）
實現控制邏輯中的聯鎖判斷、報警觸發、信號中繼和狀態反饋
作為 TEL EPC 系列控制平臺的一部分參與設備自動化流程控制
二、典型應用領域
該 I/O 模塊廣泛應用于 TEL 各類設備中的以下控制區域：
1. 晶圓搬運系統（Transfer System）
管理機械臂、載臺、旋轉軸的傳感器與馬達信號
實現搬運路徑上的多點檢測與動作控制
2. 氣體/液體流體系統（Gas/Chemical Handling）
采集 MFC、壓力傳感器、液位開關等輸入信號
輸出控制信號至電磁閥、泵、氣體分配裝置
3. 真空系統與 Loadlock 區域
檢測真空狀態、閘門位置、溫度和報警條件
控制真空閥門開關、電加熱元件等
4. 清洗/光刻輔助系統（Wet Station / Litho Support）
實時管理噴淋、烘干、旋轉平臺等設備子功能
維持多變量工藝條件下的精準控制輸出
英文資料：
1、 Function Overview
The EPC-T0091A-11 input/output module is a key component of the control system in TEL semiconductor equipment, mainly used to transmit and convert signals between the main control system and equipment execution/detection elements. Its core functions include:
Receive various input signals from sensors (such as photoelectric, limit, temperature, pressure, etc.)
Output control signals to actuators (such as relays, solenoid valves, motor drivers, etc.)
Implement interlocking judgment, alarm triggering, signal relay, and status feedback in control logic
Participate in equipment automation process control as part of TEL EPC series control platform
2、 Typical application areas
This I/O module is widely used in the following control areas of various TEL devices:
1. Wafer Transfer System
Manage sensors and motor signals for robotic arms, platforms, and rotating axes
Realize multi-point detection and action control on the transportation path
2. Gas/Chemical Handling System
Collect input signals from MFC, pressure sensors, liquid level switches, etc
Output control signals to solenoid valves, pumps, and gas distribution devices
3. Vacuum system and Loadlock area
Detect vacuum status, gate position, temperature, and alarm conditions
Control vacuum valve switches, electric heating elements, etc
4. Cleaning/Litho Support System (Wet Station/Litho Support)
Real time management of equipment sub functions such as spraying, drying, and rotating platforms
Maintain precise control output under multivariate process conditions
2.產 品 展 示
