TEL Tokyo Electron 3281-000080-13輸入/輸出板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、功能概述
該 I/O 板為 TEL 半導體設備中常見的控制接口部件，主要功能包括：
實現設備控制系統中 數字和/或模擬信號的輸入與輸出處理
作為信號中繼橋梁連接主控單元與各類傳感器、執行器
提供 信號隔離、電平匹配、狀態指示 等關鍵功能
支持聯鎖邏輯、報警觸發、控制執行等任務
二、典型應用領域
該板卡通常用于 TEL 設備的以下子系統中：
1. 氣體/液體控制系統
輸入：采集氣體流量計、壓力傳感器、液位傳感器的信號
輸出：驅動電磁閥、泵、電加熱單元等設備
2. 真空腔體/Loadlock 系統
處理真空壓力開關、門體開關、腔體溫控元件的信號
管理腔體內氣體控制元件與安全聯鎖機制
3. 晶圓搬運模塊（Transfer）
接入機械臂位置傳感器、限位開關、編碼器等信號
控制升降裝置、旋轉平臺、搬運驅動馬達等部件
4. 清洗/烘干/輔助模塊
控制液體噴淋、風扇、干燥電加熱器等輔助工藝裝置
實時采集狀態反饋，用于工藝狀態確認
英文資料：
1、 Function Overview
This I/O board is a common control interface component in TEL semiconductor equipment, and its main functions include:
Implement input and output processing of digital and/or analog signals in equipment control systems
As a signal relay bridge connecting the main control unit with various sensors and actuators
Provide key functions such as signal isolation, level matching, and status indication
Support tasks such as interlocking logic, alarm triggering, and control execution
2、 Typical application areas
This board is typically used in the following subsystems of TEL equipment:
1. Gas/liquid control system
Input: Collect signals from gas flow meters, pressure sensors, and liquid level sensors
Output: Drive electromagnetic valves, pumps, electric heating units and other equipment
2. Vacuum chamber/Loadlock system
Processing signals from vacuum pressure switches, door switches, and chamber temperature control components
Manage gas control components and safety interlock mechanisms inside the chamber
3. Wafer Transfer Module
Connect signals from robotic arm position sensors, limit switches, encoders, etc
Control the lifting device, rotating platform, handling drive motor and other components
4. Cleaning/drying/auxiliary modules
Control auxiliary process equipment such as liquid spray, fan, and drying electric heater
Real time collection of status feedback for process status confirmation
2.產 品 展 示
