TEL Tokyo Electron SPC-T0040A-11電路板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron SPC-T0040A-11 電路板 是 Tokyo Electron 半導體設備中的專用電子模塊，常見于其前道或后道工藝系統中，如涂膠顯影、CVD、蝕刻等設備中，用于支持設備控制與信號處理功能。
一、基本信息
產品型號：SPC-T0040A-11
產品類型：控制類或接口類電路板
制造商：TEL（Tokyo Electron Limited）
主要用途：在TEL設備中處理控制信號、接口轉換或執行元件控制
二、功能特點
| 功能類別 | 描述 |
|---|---|
| 控制功能 | 接收主控系統的指令，驅動子系統（如馬達、閥門、電磁裝置等） |
| 信號接口 | 與上位主控板（如CPU板）進行數據或狀態信號的交換 |
| 電壓/電流管理 | 提供穩定的信號電壓通道，具有限流、保護等功能 |
| 設備通信橋接 | 在多個子系統之間建立通信通道，保障系統協同運行 |
The TEL Tokyo Electron SPC-T0040A-11 circuit board is a specialized electronic module in Tokyo Electron semiconductor equipment, commonly used in its front-end or back-end process systems, such as coating and development CVD、 Used in etching and other equipment to support device control and signal processing functions.
1、 Basic Information
Product model: SPC-T0040A-11
Product Type: Control or Interface Circuit Board
Manufacturer: TEL (Tokyo Electron Limited)
Main purpose: Processing control signals, interface conversion, or executing component control in TEL equipment
2、 Functional Features
Functional category description
The control function receives instructions from the main control system and drives subsystems such as motors, valves, electromagnetic devices, etc
The signal interface exchanges data or status signals with the upper control board (such as CPU board)
Voltage/current management provides a stable signal voltage channel with functions such as current limiting and protection
Device communication bridging establishes communication channels between multiple subsystems to ensure collaborative operation of the system
2.產 品 展 示
