TEL Tokyo Electron 2981-600550-11輸入輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、基本信息
產品型號：2981-600550-11
產品名稱：輸入輸出模塊（I/O Module）
制造商：TEL — Tokyo Electron Limited（東京電子）
模塊類別：數字/模擬輸入輸出板，常用于設備內部信號控制系統
修訂版本：11（代表第11版，適用于特定硬件或固件版本）
二、主要功能
| 功能分類 | 功能描述 |
|---|---|
| 數字輸入 | 接收外部信號，如傳感器、按鈕、接近開關等狀態反饋。 |
| 數字輸出 | 向設備執行器發出開/關控制信號，如繼電器、電磁閥、燈光等。 |
| 模擬接口 | 可能支持部分模擬信號（如溫度、壓力、電壓等）的采集與輸出（若配置有模擬通道）。 |
| 信號中轉/隔離 | 實現上位控制系統與底層設備之間的電氣隔離和信號放大。 |
| 模塊間通信 | 與主控制板或PLC進行高速數據交換，支持 TEL 專用通信協議。 |
三、典型應用領域
該模塊廣泛應用于 TEL 半導體設備的多個子系統中，主要包括：
涂膠顯影系統（Coater/Developer）
控制顯影泵、加熱臺、排氣風扇、液體閥門、真空模塊等。
蝕刻系統（Etcher）
監控腔體氣體狀態，控制流量切換閥、高頻電源狀態、腔體門等。
CVD / ALD 薄膜沉積設備
管理溫控系統、真空壓力監測、氣體切換、等離子體啟動信號等。
搬運與真空接口系統
用于檢測腔體門開閉、升降平臺位置、機械臂狀態等信號反饋。
英文資料：
1、 Basic Information
Product model: 2981-600550-11
Product Name: I/O Module
Manufacturer: TEL - Tokyo Electron Limited
Module category: Digital/Analog Input/Output Board, commonly used for internal signal control systems of equipment
Revised version: 11 (representing the 11th edition, applicable to specific hardware or firmware versions)
2、 Main functions
Function Classification Function Description
Digital inputs receive external signals such as sensors, buttons, proximity switches, and other status feedback.
Digital output sends on/off control signals to device actuators, such as relays, solenoid valves, lights, etc.
The analog interface may support the acquisition and output of some analog signals (such as temperature, pressure, voltage, etc.) (if configured with analog channels).
Signal relay/isolation realizes electrical isolation and signal amplification between the upper control system and the underlying equipment.
High speed data exchange between modules and the main control board or PLC, supporting TEL dedicated communication protocol.
3、 Typical application areas
This module is widely used in multiple subsystems of TEL semiconductor equipment, mainly including:
Coater/Developer system
Control the developing pump, heating station, exhaust fan, liquid valve, vacuum module, etc.
Etcher system
Monitor the gas status of the chamber, control the flow switching valve, high-frequency power status, chamber door, etc.
CVD/ALD thin film deposition equipment
Manage temperature control system, vacuum pressure monitoring, gas switching, plasma start signal, etc.
Handling and Vacuum Interface System
Used to detect the opening and closing of the chamber door, the position of the lifting platform, the status of the robotic arm, and other signal feedback.
2.產 品 展 示
