TEL Tokyo Electron 5044-000281-11附加板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、基本信息
產品型號：5044-000281-11
產品名稱：附加板（Extension Board / Add-on Board）
制造商：Tokyo Electron（TEL）
模塊類型：輔助擴展板，用于增強主控制系統功能
版本號：第11版，適配特定設備或系統配置
二、主要功能
功能擴展：為主控制板或主系統增加額外的接口或信號處理能力
信號分配：處理來自主板或外設的信號，進行再分配或轉換
接口橋接：連接多種外部設備，如傳感器、執行器、通訊模塊等
系統兼容：確保系統模塊間的兼容性與數據通信穩定性
三、典型應用領域
半導體制造設備中，如光刻機前處理系統、涂膠顯影設備
薄膜沉積、蝕刻設備的子系統擴展
真空系統、搬運模塊的信號接口輔助
其他需要額外信號處理或功能擴展的設備模塊
四、模塊特點
高度定制，完全適配 TEL 專用設備系統
支持多種工業級接口，確保信號傳輸穩定
結構緊湊，方便集成于設備機柜內部
版本號“-11”表示多次優化后的硬件修訂版本
英文資料：
1、 Basic Information
Product model: 5044-000281-11
Product Name: Extension Board/Add on Board
Manufacturer: Tokyo Electron (TEL)
Module type: Auxiliary expansion board, used to enhance the functionality of the main control system
Version number: 11th edition, adapted to specific device or system configurations
2、 Main functions
Function expansion: Add additional interfaces or signal processing capabilities to the main control board or main system
Signal allocation: Processing signals from the motherboard or peripherals for redistribution or conversion
Interface bridging: connecting various external devices such as sensors, actuators, communication modules, etc
System compatibility: Ensure compatibility between system modules and stability of data communication
3、 Typical application areas
In semiconductor manufacturing equipment, such as pre-processing systems for lithography machines and coating and developing equipment
Subsystem expansion of thin film deposition and etching equipment
Signal interface assistance for vacuum systems and handling modules
Other device modules that require additional signal processing or functional expansion
4、 Module features
Highly customized, fully compatible with TEL dedicated equipment systems
Support multiple industrial grade interfaces to ensure stable signal transmission
Compact structure, easy to integrate inside the equipment cabinet
Version number "-11" represents the hardware revision version after multiple optimizations
2.產 品 展 示
3.其他產品
BENTLY 3500/22M 146031-01瞬態數據接口模塊
4.其他英文產品
Asea EB0524B01 driver input power board
| 269PLUS-W-10C-HI | SR85200-000000 | 61-600406-003 |
| 269PLUS-W-100P-HI | S31061-NA | 720-06888-000 |
| 269PLUS-W-100P-120VAC | 8010-SFI-537 | 073-775012-00 |
| 269PLUS-W-100P-120 | 8010-SFI-534 | 0053946-000 |
| 269PLUS-DO-315-100P-HI | 8010-SFI-533 | IC3600TFMA1 |
| 269PLUS-DO-311-100P-HI | 8010-SFI-510 | IC3600TFCU1D1C |
| 269PLUS-DO-271-100P-120 | 8010-SFI-324 | IC3600TFCU1C1B |
