TEL Tokyo Electron CPC-T0033A-12輸入輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、基本信息
產品型號：CPC-T0033A-12
產品名稱：輸入輸出模塊（Input/Output Module）
制造商：Tokyo Electron Limited（TEL）
產品類別：I/O 接口板 / 控制擴展模塊
修訂版本：-12 表示該型號的第 12 版，適配特定設備配置或軟件版本
二、主要功能
| 功能類別 | 描述 |
|---|---|
| 數字輸入 | 接收開關量信號，如限位開關、傳感器、按鈕狀態等 |
| 數字輸出 | 控制執行器，如電磁閥、繼電器、指示燈等開/關狀態 |
| 模擬接口（視配置） | 部分版本可能支持模擬量輸入/輸出，用于采集電壓、電流、溫度等信號 |
| 信號隔離與緩沖 | 提供電氣隔離與信號穩定性，避免設備間干擾 |
| 系統通信接口 | 連接主控制單元，實現實時數據傳輸與控制指令響應 |
三、應用場景
CPC-T0033A-12 廣泛應用于 TEL 的多種半導體設備中，用于實現設備信號的統一管理與執行控制，常見于：
光刻前后處理設備（如 ACT 系列）：
控制顯影臂、傳感器反饋、液體控制閥門、升降機構等CVD / Etch 系統：
接收壓力、真空、氣體流量等信號，控制開關元件、輔助機構搬運系統 / Transfer Modules：
管理搬運機械臂、轉臺限位、門鎖控制等關鍵動作信號
英文資料：
1、 Basic Information
Product model: CPC-T0033A-12
Product Name: Input/Output Module
Manufacturer: Tokyo Electron Limited (TEL)
Product Category: I/O Interface Board/Control Expansion Module
Revision version: -12 represents the 12th edition of this model, adapted to specific device configurations or software versions
2、 Main functions
Functional category description
Digital input receives switch signals, such as limit switches, sensors, button status, etc
Digital output controls the on/off status of actuators such as solenoid valves, relays, indicator lights, etc
Partial versions of the analog interface (depending on configuration) may support analog input/output for collecting signals such as voltage, current, temperature, etc
Signal isolation and buffering provide electrical isolation and signal stability, avoiding interference between devices
The system communication interface is connected to the main control unit to achieve real-time data transmission and control command response
3、 Application scenarios
CPC-T0033A-12 is widely used in various semiconductor devices of TEL to achieve unified management and execution control of device signals. It is commonly used in:
Photolithography pre-processing and post-processing equipment (such as ACT series):
Control the developing arm, sensor feedback, liquid control valve, lifting mechanism, etc
CVD/Etch system:
Receive signals such as pressure, vacuum, gas flow, etc., and control switch components and auxiliary mechanisms
Transfer Modules:
Manage key action signals such as handling robotic arm, turntable limit, door lock control, etc
2.產 品 展 示
