TEL Tokyo Electron 381-64227-3數字量輸入卡件 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、基本信息
產品型號：381-64227-3
產品名稱：數字量輸入卡件（Digital Input Card）
制造商：Tokyo Electron Limited（TEL，日本東京電子）
卡件類型：數字輸入模塊 / DI 板卡
版本號：-3（表示該卡件的第3個修訂版或硬件版本）
二、主要功能
該卡件用于接收和處理來自現場設備的開關量信號（DI），是 TEL 控制系統中狀態檢測與事件觸發的關鍵部件之一。
| 功能類別 | 描述 |
|---|---|
| 數字輸入采集 | 接收按鈕、限位開關、干接點傳感器等的開關狀態信號 |
| 狀態上報 | 將輸入狀態反饋至主控制器，用于動作判斷與流程邏輯執行 |
| 電氣隔離保護 | 每個輸入通道具備隔離電路，防止信號干擾、反灌電流 |
| 支持邏輯觸發 | 輸入信號可定義為常開（NO）或常閉（NC）邏輯，根據工藝需求配置 |
三、應用領域
該卡件主要用于 TEL 各類半導體制造設備中的數字狀態監控和互鎖控制系統，廣泛應用于：
ACT 系列（光刻輔助設備）
監測腔體門狀態、平臺就位、晶圓存在、真空狀態等開關量輸入
Tactras 系列（蝕刻設備）
檢測氣體閥門狀態、安全門開關、冷卻水壓力繼電器狀態
Trias 系列（沉積設備）
用于沉積工藝步驟中的安全互鎖信號采集、電磁動作反饋信號接入
EFEM / Transfer / Load Port 模塊
判斷載片單元是否到位、卡匣門是否關閉、機械臂是否歸位等狀態
英文資料：
1、 Basic Information
Product model: 381-64227-3
Product Name: Digital Input Card
Manufacturer: Tokyo Electron Limited (TEL, Tokyo Electronics, Japan)
Card type: Digital input module/DI board
Version number: -3 (indicating the third revision or hardware version of the card)
2、 Main functions
This card is used to receive and process switch signals (DI) from field devices, and is one of the key components for state detection and event triggering in TEL control systems.
Functional category description
Digital input collects switch status signals of receiving buttons, limit switches, dry contact sensors, etc
Status reporting feeds back the input status to the main controller for action judgment and process logic execution
Electrical isolation protection: Each input channel is equipped with an isolation circuit to prevent signal interference and backflow current
Support logic triggering input signals can be defined as normally open (NO) or normally closed (NC) logic, configured according to process requirements
3、 Application Fields
This card is mainly used for digital status monitoring and interlock control systems in various semiconductor manufacturing equipment of TEL, and is widely used in:
ACT series (lithography auxiliary equipment)
Monitor the status of the chamber door, platform positioning, wafer presence, vacuum status, and other switch inputs
Tactras series (etching equipment)
Detect the status of gas valves, safety door switches, and cooling water pressure relays
Trias series (sedimentation equipment)
Used for safety interlock signal acquisition and electromagnetic action feedback signal access in sedimentation process steps
EFEM/Transfer/Load Port module
Determine whether the loading unit is in place, whether the cartridge door is closed, and whether the robotic arm is in place
2.產 品 展 示
