TEL Tokyo Electron 2981-600534-1印刷電路板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 2981-600534-1 印刷電路板是一款應用于半導體制造設備中的專用控制板卡，主要作用是實現設備內部各子系統的信號采集、控制執行和通信管理。該電路板主要應用于以下幾個領域：
一、典型應用設備類型
干法刻蝕設備（Etcher）
薄膜沉積設備（CVD、ALD等）
光刻膠涂布/顯影設備（Track System）
晶圓清洗設備（Wafer Cleaner）
二、功能定位
控制模塊：驅動執行部件如電磁閥、馬達、溫控單元等
信號處理：采集傳感器信號，處理溫度、壓力、流量等數據
通信接口：與上位控制系統（如主控板、工控機）進行高速通信
故障診斷：記錄設備運行數據并支持故障檢測與報警反饋
三、主要應用場景
晶圓制程工段中的多腔室協調控制
制程環境監控與自動化調節
化學品供給系統的實時控制
封裝前高精度工藝參數控制
四、應用優勢
提高系統控制響應速度與數據傳輸穩定性
支持多任務并行處理與模塊化擴展
適用于潔凈室內高標準工業控制環境
英文資料：
TEL Tokyo Electron 2981-600534-1 printed circuit board is a specialized control board used in semiconductor manufacturing equipment, mainly responsible for signal acquisition, control execution, and communication management of various subsystems within the equipment. This circuit board is mainly used in the following fields:
1、 Typical application device types
Dry etching equipment (Etcher)
Thin film deposition equipment (CVD, ALD, etc.)
Photoresist coating/developing equipment (Track System)
Wafer Cleaner
2、 Functional positioning
Control module: drives execution components such as solenoid valves, motors, temperature control units, etc
Signal processing: Collecting sensor signals, processing temperature, pressure, flow rate and other data
Communication interface: high-speed communication with the upper control system (such as the main control board and industrial computer)
Fault diagnosis: Record equipment operation data and support fault detection and alarm feedback
3、 Main application scenarios
Multi chamber coordinated control in wafer process section
Process environment monitoring and automation adjustment
Real time control of chemical supply system
High precision process parameter control before packaging
4、 Application advantages
Improve system control response speed and data transmission stability
Support multitasking parallel processing and modular expansion
Suitable for high standard industrial control environments in clean rooms
2.產 品 展 示
