TEL Tokyo Electron 1181-000540-13限制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 1181-000540-13 限制板（Limiter Board）是用于TEL半導體制造設備中的電子功能模塊，主要承擔信號限制、保護和電平控制等安全功能。該板卡通常集成在關鍵工藝系統中，保護主控制系統及敏感部件免受異常電壓或信號干擾。
一、基本信息
產品名稱：限制板 / 限流板
型號：1181-000540-13
制造商：Tokyo Electron Ltd. (TEL)
組件類型：印刷電路板（PCB）
功能類別：信號限制與保護類模塊
二、主要功能
電壓/電流限制
防止輸入信號超過設定閾值，保護主控電路或敏感器件；
抑制突波、浪涌或外部干擾信號。
信號電平匹配
實現不同子系統之間的電氣隔離與電平轉換；
保證系統整體信號傳輸?shù)姆€(wěn)定性與兼容性。
設備運行保護
在設備異常狀態（如短路、過載）時自動中斷或限制信號；
避免損壞核心控制模塊或昂貴部件。
英文資料：
The TEL Tokyo Electron 1181-000540-13 limiter board is an electronic functional module used in TEL semiconductor manufacturing equipment, mainly responsible for safety functions such as signal limitation, protection, and level control. This board is usually integrated into critical process systems to protect the main control system and sensitive components from abnormal voltage or signal interference.
1、 Basic Information
Product Name: Limiting Plate/Current Limiting Plate
Model: 1181-000540-13
Manufacturer: Tokyo Electron Ltd. (TEL)
Component type: Printed Circuit Board (PCB)
Function category: Signal restriction and protection module
2、 Main functions
Voltage/current limitation
Prevent input signals from exceeding the set threshold and protect the main control circuit or sensitive components;
Suppress sudden waves, surges, or external interference signals.
Signal level matching
Implement electrical isolation and level conversion between different subsystems;
Ensure the stability and compatibility of the overall signal transmission of the system.
Equipment operation protection
Automatically interrupt or limit signals when the device is in an abnormal state (such as short circuit, overload);
Avoid damaging the core control module or expensive components.
2.產 品 展 示
