TEL Tokyo Electron 1381-644-380-1 傳感器板（Sensor Board）**是專為半導體制造設備設計的高精度信號采集模塊，主要用于對設備運行環境或工藝狀態的關鍵參數進行實時檢測與反饋。此類模塊在TEL的刻蝕、CVD、清洗等核心設備中發揮著非常重要的控制支持作用。
一、基本信息
產品名稱：傳感器板 / 傳感器模塊
型號：1381-644-380-1
制造商：Tokyo Electron Ltd. (TEL)
模塊類型：高精度信號采集與處理板卡
安裝位置：嵌入TEL設備控制柜或與執行部件（如加熱器、泵、閥門）相連
二、主要功能
環境與工藝參數采集
實時采集溫度、壓力、氣體流量、腔體真空度、RF功率等工藝數據。
信號調理與傳輸
對模擬/數字信號進行放大、濾波、電平轉換等處理，并傳輸至主控系統。
工藝控制反饋
為PID回路、自動調整邏輯提供輸入，支撐精確過程控制。
報警聯動功能
超限或異常信號可觸發報警、停機或安全聯鎖動作，確保設備與產品安全。
三、典型應用領域
該傳感器板可廣泛部署于以下TEL設備系統中：
Etching Systems（刻蝕系統）
監控腔體內壓力、氣體流量、等離子體狀態等。CVD/ALD（化學氣相沉積系統）
檢測加熱器溫度、反應腔壓強、 precursor輸送情況。Track Systems（光刻膠處理設備）
用于顯影液濃度、溫控水路、烘烤區溫度監控。Wet Clean / CMP（濕法清洗或化學機械研磨）
檢測化學液流量、壓力、PH值或腔體液位等。
英文資料：
TEL Tokyo Electron 1381-644-380-1 Sensor Board * * is a high-precision signal acquisition module designed specifically for semiconductor manufacturing equipment, mainly used for real-time detection and feedback of key parameters of equipment operating environment or process status. This type of module is etched in TEL CVD、 Cleaning and other core equipment play a very important role in control and support.
1、 Basic Information
Product Name: Sensor Board/Sensor Module
Model: 1381-644-380-1
Manufacturer: Tokyo Electron Ltd. (TEL)
Module type: high-precision signal acquisition and processing board
Installation location: Embedded in TEL equipment control cabinet or connected to executing components (such as heaters, pumps, valves)
2、 Main functions
Collection of environmental and process parameters
Real time collection of process data such as temperature, pressure, gas flow rate, chamber vacuum degree, RF power, etc.
Signal conditioning and transmission
Amplify, filter, and level convert analog/digital signals, and transmit them to the main control system.
Process control feedback
Provide input for PID circuits and automatic adjustment logic to support precise process control.
Alarm linkage function
Overlimit or abnormal signals can trigger alarms, shutdowns, or safety interlock actions to ensure the safety of equipment and products.
3、 Typical application areas
This sensor board can be widely deployed in the following TEL device systems:
Etching Systems
Monitor the pressure, gas flow rate, plasma state, etc. inside the chamber.
CVD/ALD (Chemical Vapor Deposition System)
Detect heater temperature, reaction chamber pressure, and precursor delivery status.
Track Systems (photoresist processing equipment)
Used for monitoring developer concentration, temperature controlled water circuit, and baking area temperature.
Wet Clean/CMP (wet cleaning or chemical mechanical polishing)
Detect chemical liquid flow rate, pressure, pH value, or chamber liquid level, etc.
