TEL Tokyo Electron 381-639094-4數字量輸入卡件 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 381-639094-4 數字量輸入卡件（Digital Input Card） 是一款專用于TEL半導體設備中的電子信號采集模塊，負責接收和處理來自外部設備的數字信號，實現工藝過程中的狀態監控、設備聯鎖和邏輯判斷等功能。
一、基本信息
產品名稱：數字量輸入卡件 / 數字輸入模塊
產品型號：381-639094-4
制造商：Tokyo Electron Ltd.（TEL）
模塊類型：數字輸入信號采集板（DI模塊）
應用范圍：Etcher、CVD、清洗、Track 等TEL自動化制程設備
二、主要功能
信號采集
接收來自開關、傳感器、繼電器、光電檢測等設備的開關信號（ON/OFF）。
邏輯判斷
將輸入信號傳送至主控制系統（如PLC或工業PC），用于設備運行邏輯的判斷和流程推進。
安全聯鎖支持
輸入信號可作為設備啟動、腔體閉鎖、真空狀態確認等聯鎖條件之一。
狀態反饋監控
通過數字輸入監控關鍵機構（如門控、氣閥、機械臂）的實際狀態，確保工藝過程安全執行。
三、典型應用領域
該卡件廣泛應用于TEL多個核心設備系統中，具體包括：
干法刻蝕設備（Etcher）
接收門控、真空到位信號，參與等離子啟動聯鎖。
CVD / ALD設備
接收反應腔體開閉狀態、氣體閥門狀態等信息。
晶圓清洗設備
檢測化學液供給狀態、泵啟動信號、液位傳感器反饋。
光刻膠處理設備（Track System）
接收托盤位置、晶圓載入、加熱模塊門狀態等數字反饋信號。
英文資料：
TEL Tokyo Electron 381-639094-4 Digital Input Card is an electronic signal acquisition module specifically designed for TEL semiconductor equipment. It is responsible for receiving and processing digital signals from external devices, achieving functions such as status monitoring, equipment interlocking, and logic judgment during the process.
1、 Basic Information
Product Name: Digital Input Card/Digital Input Module
Product model: 381-639094-4
Manufacturer: Tokyo Electron Ltd. (TEL)
Module type: Digital input signal acquisition board (DI module)
Application scope: TEL automation process equipment such as Etcher, CVD, cleaning, Track, etc
2、 Main functions
signal acquisition
Receive switch signals (ON/OFF) from devices such as switches, sensors, relays, and photodetectors.
logical judgment
Transmit input signals to the main control system (such as PLC or industrial PC) for the judgment of equipment operation logic and process advancement.
Safety interlock support
The input signal can be used as one of the interlocking conditions for device startup, chamber locking, vacuum status confirmation, etc.
Status feedback monitoring
Monitor the actual status of key mechanisms such as door control, air valves, and robotic arms through digital inputs to ensure safe execution of the process.
3、 Typical application areas
This card is widely used in multiple core equipment systems of TEL, including:
Dry etching equipment (Etcher)
Receive gate control and vacuum in place signals, and participate in plasma start interlocking.
CVD/ALD equipment
Receive information on the opening and closing status of the reaction chamber, gas valve status, etc.
Wafer Cleaning Systems
Detect the supply status of chemical solution, pump start signal, and liquid level sensor feedback.
Photoresist processing equipment (Track System)
Receive digital feedback signals such as tray position, wafer loading, and heating module door status.
