TEL Tokyo Electron EC08-000007-11控制脈沖卡件 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron EC08-000007-11 控制脈沖卡件（Control Pulse Card） 是TEL半導體制造設備中用于精確脈沖信號產生和控制的電子模塊，廣泛應用于設備的運動控制、步進執行和時序管理等關鍵領域。
一、基本信息
產品名稱：控制脈沖卡件
型號：EC08-000007-11
制造商：Tokyo Electron Ltd.（TEL）
模塊類型：脈沖信號生成與控制模塊
應用領域：設備運動控制、驅動脈沖生成、自動化時序控制
二、主要功能
脈沖信號輸出
產生精準的脈沖序列，用于驅動步進電機、伺服驅動器等執行機構。
支持多種脈沖頻率和脈寬調節，以滿足不同驅動需求。
同步控制
與主控系統協同，實現多軸同步運動和時序精確控制。
保證設備動作的準確性和重復定位精度。
信號轉換與放大
將主控器發出的控制信號轉換成適合執行器接收的脈沖電平。
提供隔離和緩沖，防止干擾和信號衰減。
接口兼容
適配TEL設備的標準通信和控制接口，實現快速集成。
三、典型應用領域
晶圓搬運系統（Wafer Handling）
控制機械手臂的步進電機，精準定位晶圓位置。光刻設備中的旋轉與定位控制
生成控制涂膠旋轉平臺或曝光定位機構的脈沖信號。刻蝕與沉積設備運動單元
驅動閥門調節機構、快門控制、樣品臺運動。
英文資料：
TEL Tokyo Electron EC08-000007-11 Control Pulse Card is an electronic module used in TEL semiconductor manufacturing equipment for precise pulse signal generation and control. It is widely used in key fields such as motion control, step execution, and timing management of equipment.
1、 Basic Information
Product Name: Control Pulse Card
Model: EC08-000007-11
Manufacturer: Tokyo Electron Ltd. (TEL)
Module type: Pulse signal generation and control module
Application areas: equipment motion control, drive pulse generation, automated timing control
2、 Main functions
Pulse signal output
Generate precise pulse sequences for driving actuators such as stepper motors and servo drives.
Support multiple pulse frequencies and pulse width adjustments to meet different driving requirements.
synchronization
Collaborate with the main control system to achieve multi axis synchronous motion and precise timing control.
Ensure the accuracy of device actions and repeat positioning precision.
Signal conversion and amplification
Convert the control signal emitted by the main controller into a pulse level suitable for the actuator to receive.
Provide isolation and buffering to prevent interference and signal attenuation.
Interface compatibility
Adapt to the standard communication and control interfaces of TEL devices to achieve rapid integration.
3、 Typical application areas
Wafer Handling System
Control the stepper motor of the robotic arm to accurately position the wafer.
Rotation and positioning control in lithography equipment
Generate pulse signals to control the adhesive rotation platform or exposure positioning mechanism.
Etching and deposition equipment motion unit
Drive valve adjustment mechanism, shutter control, and sample stage movement.
