TEL Tokyo Electron EC81-000053-11數字量控制板卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron EC81-000053-11 數字量控制板卡（Digital I/O Control Board） 是用于TEL半導體設備中的關鍵控制模塊之一，負責數字輸入/輸出信號的處理與執行控制任務。該板卡在TEL的多個核心設備系統中廣泛部署，尤其用于執行機械聯動、設備狀態監控、安全聯鎖及工藝流程邏輯控制。
一、基本信息
產品名稱：數字量控制板卡
產品型號：EC81-000053-11
制造商：Tokyo Electron Ltd.（TEL）
板卡類型：數字輸入/輸出控制模塊（Digital I/O Board）
部署位置：設備電控機柜或模塊控制系統中
二、主要功能
數字信號輸入處理（DI）
接收來自傳感器、限位開關、按鈕、繼電器等外部設備的開關信號；
判斷設備運行狀態、物理位置狀態或過程觸發條件。
數字信號輸出控制（DO）
輸出控制信號至執行器件，如繼電器、氣動閥、電磁鎖、指示燈等；
用于設備動作控制、狀態反饋或安全聯鎖輸出。
狀態監測與邏輯控制
配合主控制器（PLC/嵌入式系統）實現流程邏輯、故障響應、自動切換等任務。
通信與同步
通過背板總線或?qū)Ｓ每刂瓶偩€與主控系統進行通信，參與多模塊同步運行。
三、典型應用領域
| 應用設備 | 控制任務 |
|---|---|
| Etcher（干法刻蝕） | 控制氣閥開關、等離子體啟停、安全門狀態檢測等 |
| CVD/ALD設備 | 管理氣體供給閥、電源聯鎖、溫控系統啟停 |
| 光刻涂膠設備（Track） | 控制晶圓傳輸動作、烘烤單元門控、顯影流程邏輯 |
| 晶圓搬運系統 | 檢測機械臂到位、真空吸附、托盤狀態等信號 |
英文資料：
The TEL Tokyo Electron EC81-000053-11 Digital I/O Control Board is one of the key control modules used in TEL semiconductor equipment, responsible for processing and executing control tasks for digital input/output signals. This board is widely deployed in multiple core equipment systems of TEL, especially for performing mechanical linkage, equipment status monitoring, safety interlocking, and process logic control.
1、 Basic Information
Product Name: Digital Control Board
Product model: EC81-000053-11
Manufacturer: Tokyo Electron Ltd. (TEL)
Board type: Digital I/O Board
Deployment location: In the equipment control cabinet or module control system
2、 Main functions
Digital Signal Input Processing (DI)
Receive switch signals from external devices such as sensors, limit switches, buttons, relays, etc;
Determine the operational status, physical location status, or process triggering conditions of the equipment.
Digital Signal Output Control (DO)
Output control signals to actuators such as relays, pneumatic valves, electromagnetic locks, indicator lights, etc;
Used for equipment action control, status feedback, or safety interlock output.
State monitoring and logic control
Collaborate with the main controller (PLC/embedded system) to implement tasks such as process logic, fault response, and automatic switching.
Communication and synchronization
Communicate with the main control system through the backplane bus or dedicated control bus to participate in synchronous operation of multiple modules.
3、 Typical application areas
Application device control tasks
Etcher (dry etching) control valve switch, plasma start stop, safety door status detection, etc
CVD/ALD equipment management gas supply valve, power interlock, temperature control system start stop
Photolithography coating equipment (Track) controls wafer transfer actions, baking unit gate control, and development process logic
The wafer handling system detects signals such as the arrival of the robotic arm, vacuum suction, and tray status
2.產 品 展 示
