TEL Tokyo Electron 3D81-000038-V2印刷電路板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 3D81-000038-V2 印刷電路板（Printed Circuit Board，PCB） 是一款用于TEL半導體制造設備中的專用電子控制模塊，通常用于實現信號中繼、系統邏輯控制、接口處理或功能電路集成。該電路板作為設備系統中的核心組件之一，承擔著特定子系統的信號連接與邏輯執行功能。
一、基本信息
產品名稱：印刷電路板 / 控制電路板
產品型號：3D81-000038-V2
制造商：Tokyo Electron Ltd.（TEL）
功能類型：控制邏輯電路板 / 接口轉換板 / 中繼處理板（具體取決于設備型號）
典型安裝位置：設備主控機架、電控箱、IO接口系統中
二、主要功能（視具體配置而定）
信號中繼與分配
連接主控系統與子系統（如傳感器、執行器、閥控模塊等），實現信號中轉和邏輯判斷。
接口協議處理
執行信號電平匹配、通信協議轉換（如TTL ? RS-232/485）等功能。
系統邏輯控制
集成專用電路（如微控制器、邏輯門陣列、放大器等），用于執行特定工藝步驟的控制邏輯。
保護與隔離功能
實現電源、電信號的隔離與保護，如ESD防護、電源濾波等。
三、典型應用設備
該P(yáng)CB模塊常應用于以下TEL設備中，發揮中控輔助作用：
| 設備類型 | 應用說明 |
|---|---|
| Etcher（刻蝕設備） | 處理射頻控制信號、閥門控制、等離子源中繼邏輯 |
| CVD/ALD系統 | 管理溫控反饋信號、化學氣體切換控制 |
| Track設備（涂膠顯影） | 控制顯影單元、烘烤平臺、液體閥組件 |
| Transfer Module（搬運系統） | 處理機械手、吸盤、托盤狀態信號等 |
英文資料：
TEL Tokyo Electron 3D81-000038-V2 Printed Circuit Board (PCB) is a specialized electronic control module used in TEL semiconductor manufacturing equipment, typically for signal relay, system logic control, interface processing, or functional circuit integration. As one of the core components in the device system, this circuit board is responsible for signal connection and logic execution functions of specific subsystems.
1、 Basic Information
Product Name: Printed Circuit Board/Control Circuit Board
Product model: 3D81-000038-V2
Manufacturer: Tokyo Electron Ltd. (TEL)
Function type: Control logic circuit board/interface conversion board/relay processing board (depending on the device model)
Typical installation locations: equipment main control rack, electrical control box, IO interface system
2、 Main functions (depending on specific configuration)
Signal Relay and Distribution
Connect the main control system with subsystems (such as sensors, actuators, valve control modules, etc.) to achieve signal relay and logical judgment.
Interface protocol processing
Perform signal level matching and communication protocol conversion (such as TTL) ? Functions such as RS-232/485.
System logic control
Integrated specialized circuits (such as microcontrollers, logic gate arrays, amplifiers, etc.) are used to execute control logic for specific process steps.
Protection and isolation function
Implement isolation and protection of power and electrical signals, such as ESD protection, power filtering, etc.
3、 Typical application devices
This PCB module is commonly used in the following TEL devices to play a central control auxiliary role:
Equipment type application instructions
Etcher (etching equipment) processes RF control signals, valve control, and plasma source relay logic
CVD/ALD system management temperature control feedback signal, chemical gas switching control
Track equipment (adhesive development) controls the development unit, baking platform, and liquid valve components
Transfer Module (handling system) processes status signals of robotic arms, suction cups, trays, etc
2.產 品 展 示
