TEL Tokyo Electron 381-648286-12數字量輸入卡件 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 381-648286-12 數字量輸入卡件（Digital Input Card） 是一款專用于TEL半導體制造設備中的數字信號采集模塊，用于接收和處理來自設備各處的開關量（ON/OFF）信號，實現設備運行狀態的檢測、過程聯鎖、報警觸發等控制任務。
一、基本信息
產品名稱：數字量輸入卡件（DI卡）
產品型號：381-648286-12
制造商：Tokyo Electron Ltd.（TEL）
板卡類型：數字輸入（DI）模塊
典型位置：設備控制機柜、輸入/輸出接口框架、電氣分區模塊內
二、主要功能
開關信號采集（Digital Input）
接收來自按鈕、行程開關、接近傳感器、限位器、安全門鎖等的狀態信號（如 0/24V DC）。
判斷設備是否達到指定工藝狀態或安全條件。
狀態反饋處理
將輸入信號反饋至主控系統（如PLC、嵌入式控制器），用于驅動邏輯判斷和自動流程。
支持多通道實時掃描，確保響應速度。
聯鎖與報警觸發
輸入信號變化可觸發設備聯鎖邏輯或報警流程，保障運行安全。
系統互鎖機制
與數字輸出卡件、主控板協同，實現對設備動作的許可/禁止控制邏輯。
三、典型應用領域
| 應用系統 | 采集信號類型 |
|---|---|
| 刻蝕設備（Etcher） | 反應腔門狀態、真空開關、氣體切換完成反饋等 |
| CVD/ALD設備 | 加熱器狀態反饋、閥門到位信號、化學源保護觸發器 |
| 光刻/涂膠顯影（Track） | 晶圓在位檢測、旋轉平臺門鎖、液位報警等 |
| 搬運系統 | 機械臂限位、夾持器狀態、托盤存在檢測等 |
英文資料：
TEL Tokyo Electron 381-648286-12 Digital Input Card is a digital signal acquisition module specifically designed for TEL semiconductor manufacturing equipment. It is used to receive and process ON/OFF signals from various parts of the equipment, and to achieve control tasks such as detecting equipment operating status, process interlocking, and alarm triggering.
1、 Basic Information
Product Name: Digital Input Card (DI Card)
Product model: 381-648286-12
Manufacturer: Tokyo Electron Ltd. (TEL)
Board type: Digital Input (DI) module
Typical locations: within equipment control cabinets, input/output interface frameworks, and electrical partition modules
2、 Main functions
Switch signal acquisition (Digital Input)
Receive status signals (such as 0/24V DC) from buttons, travel switches, proximity sensors, limiters, safety door locks, etc.
Determine whether the equipment has reached the specified process state or safety conditions.
Status feedback processing
Feedback the input signal to the main control system (such as PLC, embedded controller) for driving logic judgment and automatic processes.
Support multi-channel real-time scanning to ensure response speed.
Interlocking and alarm triggering
Changes in input signals can trigger equipment interlocking logic or alarm processes, ensuring safe operation.
System interlocking mechanism
Collaborate with digital output cards and the main control board to implement permission/prohibition control logic for device actions.
3、 Typical application areas
Application system collects signal types
Etcher reaction chamber door status, vacuum switch, gas switching completion feedback, etc
CVD/ALD equipment heater status feedback, valve in place signal, chemical source protection trigger
Photolithography/coating development (Track) wafer in-situ detection, rotating platform door lock, liquid level alarm, etc
Mechanical arm limit, gripper status, pallet presence detection, etc. in the handling system
