5X00226G02隔離模塊,5X00226G02使用配置教程
主煤流運輸集控子系統，變頻、軟起部分和皮帶保護系統通過電控系統PLC配置的Modbus模塊接入各個皮帶控制子系統，各皮帶控制配置工業以太網接口模塊，膠帶機集中控制系統控制中心設在主井井口房，通過主井井口房的上位機直接接入地面工業以太環網；數據通過標準的TCP/IP數據協議傳輸?shù)秸{(diào)度中心集控室，以O(shè)PC方式實現與調度中心通信，實現集中控制礦用隔爆型真空饋電開關(以下簡稱饋電開關)主要用于煤礦井下，在交流50Hz、電壓至1140V，額定電流分別為400A、500A、630A、800A的線路中
5X00226G02隔離模塊，作為供電系統的總開關、分支開關，或作為礦用隔爆型移動變電站用饋電開關（打開后蓋板與移動變電站對接），也可作為大容量電動機不頻繁起動之用。具有過載、短路、欠壓、漏電保護(選擇性漏電保護)及漏電閉鎖等功能。產品可應用在礦用隔爆型真空饋電開關等煤礦安全用電監測系統中。該系統由一套UniMAT PLC 文本屏構成的控制系統和真空斷路器構成的執行系統構成。如圖所示。其中CPU進行一些邏輯控制，礦用模塊主要是采集AC電壓、電流和漏電電阻等信號，從而實現系統監測監控并完成漏電閉鎖、過載、短路、斷相、欠壓和過壓等保護功能，具有智能化程度高、性能穩定、動作可靠等優點。系統主要是要保證漏電保護動作時間小于50ms和短路保護動作的時間小于100ms，所以要保證CPU的采集處理運行速度很快，UniMAT PLC采用高頻微處理器，指令處理速度比普通PLC提升3-10倍，采用UniMAT UN200 PLC的采集與控制周期時間是12ms,加上外圍的設備時間30ms,共42ms，達到了設備的標準要求。采用文本顯示屏，配合UniMAT UN200系列小型PLC，實現對饋電開關的工作狀態、參數和故障類型顯示和記憶，并可對具體參數進行修改調整，友好的用戶界面，具有良好的人機對話功能，可大大提高判斷故障和排除故障的效率。
所有模擬信號全部處理為數字信號，具有抗干擾能力強、接線簡潔、信息量大、控制可靠準確等特點。
具有完備的自檢、自診斷和故障模擬實驗功能，可方便地檢查保護和控制系統正常與否。該饋電開關充分考慮煤礦井下的工作環境，集機械制造、自動化、測控技術與儀器儀表、計算機應用科學技術等學科于一身
As the key equipment of digital substation communication network, ingem Industrial Ethernet switch has strict requirements in iec61850-3, so that it can be applied stably, reliably and safely in various harsh industrial environments for a long time, and escort the digital substation. The communication network of digital substation must meet the special requirements of real-time, reliability, security and expansibility. Optical fiber communication has become an ideal communication mode in digital substation because of its wide bandwidth, high reliability, strong confidentiality, good anti-interference ability and long transmission distance. Characteristics of digital substation automation system:
(1) Intelligent primary equipment: the detected signal circuit and controlled operation driving circuit of primary equipment are designed by microprocessor and photoelectric technology. The conventional relay and its logic circuit in the secondary circuit of substation are replaced by programmable controller, and the conventional strong current analog signal and control cable are replaced by photoelectric digital and optical fiber.
