常開（a觸點）或常閉（B觸點）觸點的C狀態。2.在給定開關位置，白色（W）或黑色（B）執行器下的凸輪位置。請注意，在第9頁的表2中，標準選擇開關（凸輪代碼“KB7”）以及凸輪代碼“KA1”和“KA7”的目標表是相同的，無論控制塊安裝在白色執行器或blk執行器后面。凸輪代碼“KC1”、“KC7”和“KD7”具有所有六個可用的組合。Eh標準和旋鈕操縱桿是用白色插件組裝的。機翼操縱桿操作員為標準灰色。如果訂購數量為10個或更多的裝置，則可提供其他顏色。對于標準和旋鈕操縱桿操作員，請從下表中選擇一個顏色代碼字母。在列出的目錄號中破折號后的第一個字母后插入顏色代碼字母。例如，帶有綠色插件的800T-J2KA1將是800T-JB2KA1。代碼字母顏色綠色藍色黃色ABCE對于翼?xiàng)U操作員（僅提供灰色或），將字母“G”替換為字母“a”。要訂購未安裝彩色嵌件的標準或旋鈕操縱桿，請?jiān)谒心夸浱?hào)破折號后的第一個字母后添加字母“X”。包含其中一個eh的特殊pket不收取額外費用。目標表特殊顏色公告800T油密選擇開關產品數據17選擇特殊照明選擇開關與選擇特殊非照明選擇開關類似。然而，照明設備的控制塊只能安裝在白色啟動器后面。照明設備上的燈的電源模塊必須安裝在設備的blk側后面。因此，照明設備具有2位模塊后綴代碼，而非照明設備具有4位代碼。示例：800T-16JR2KB7AX工業控制目錄中列出的照明選擇開關的后綴代碼可以修改，以實現特殊的控制布置?？梢允褂锰厥庋b置，使一個電路的觸點在第二個電路的接頭斷開之前閉合。由于這些選擇器開關可能被誤用，因此未在工業控制目錄中列出。如果您的應用程序需要重疊凸輪，請聯系最近的Allen-Bradley銷售辦公室。照明選擇開關重疊凸輪公告800T油密選擇開關
C state of a contt either normally open (A contts) or normally closed (B contts). 2. The position of the cam under the White (W) or Blk (B) tuator in the given switch position. Note in Table 2 on Page 9 the target tables for the standard selector switch (Cam Code “KB7”), plus Cam Codes “KA1”, and “KA7” are the same whether the contt blocks are mounted behind the white tuator or blk tuator. Cam Codes “KC1”, “KC7” and “KD7” have all six contt binations available. Eh standard and knob lever operator is ftory assembled with a white insert. The wing lever operator is standard as gray. Other colors are available if orde in ftory assembled quantities of 10 or more devices. For standard and knob lever operators select a color code letter from the table below. Insert the color code letter after the first letter following the dash in the listed catalog number. Example, 800T-J2KA1 with a green insert would bee 800T-JB2KA1. Code Letter Color Green Blue Yellow ABCE For a wing lever operator (only available in gray or ), reple the letter “G” with the letter “A”. To order standard or knob lever operators without color inserts installed, add the letter “X” after the first letter following the dash of the listed catalog number. A special pket containing one of eh is included at no extra charge. Target Tables Special Colors Bulletin 800T Oiltight Selector Switches Product Data 17 Selection of special illuminated selector switches is similar to selecting special non-illuminated selector switches. However, contt blocks for illuminated devices can only be mounted behind the white tuator. The power module for the lamp on illuminated devices must be mounted behind the blk side of the device. Thus, illuminated devices have a 2-digit modular suffix code versus a 4-digit code for non-illuminated devices. Example: 800T-16JR2KB7AX The suffix codes for the illuminated selector switches listed in the Industrial Control catalog can be modified to hieve special contt arrangements. Special devices are available which allow contts of one circuit to close before the contts of a second circuit open. These selector switches are not listed in the Industrial Control catalog because of their potential misuse. If your application requires overlapping cams, contt your nearest Allen-Bradley Sales Office. Illuminated Selector Switches Overlapping Cams Bulletin 800T Oiltight Selector Switches
