The MVME712 hardware preparation is provided in separate
manuals. Refer to Related Documentation in Chapter 1.
Unpacking Instructions
Note If the shipping carton is damaged upon receipt, request
that the carrier's agent be present during unpacking
and inspection of the equipment.
Unpack the equipment from the shipping carton. Refer to the
packing list and verify that all items are present. Save the packing
material for storing and reshipping of the equipment. Overview of Start-up Procedure
The following list identifies the things you will need to do before
you can use this board, and where to find the information you need
to perform each step. Be sure to read this entire chapter and read all
Caution notes before beginning. Hardware Preparation
The MVME147 has been factory tested and is shipped with factoryinstalled jumpers configured to provide the system functions
required for a VMEbus system. The module is operational with the
factory-installed jumpers, but to select the desired configuration
and ensure proper operation of the MVME147, certain option
modifications may be necessary.
Options are selected by installing or removing jumpers on the
following headers:
? ROM configuration select (J1, J2)
? System controller select (J3)
? Serial port 4 clock configuration select (J8, J9)
ROM Configuration Select Headers (J1, J2)
The MVME147 supports various sizes of EPROMs and EEPROMs.
Four 32-pin ROM/PROM/EPROM/EEPROM sockets are
provided on the module. They are organized as two banks with two
sockets per bank. Each pair of sockets may be individually
configured. Sockets U22 and U30 form bank 1. Sockets U1 and U15
form bank 2.
The banks are configured as word ports to the MPU with U22 and
U1 comprising the even bytes and U30 and U15 the odd bytes.
